• Model NO.：QY25V532
• Shaft Number：3
• Crane Jib：Four-Arm
• Type：Straight Arm
• Engine：Weichai
• Transport Package：Nude
• Specification：ISO
• Trademark：ZOOMLION
• Origin：China
• HS Code：8705109100
• Production Capacity：50 Sets,Month

ItemValueRemarksWorking performanceMax. rated lifting capacity kg25000 Max. load moment of basic boom kN.m980 Max. load moment of max. boom length kN.m494 Max. lifting height of basic boom m11.0 Max. lifting height of boom m39Deformation of the boom is not taken into consideration.Max. lifting height of jib m47.0Working speedMax. hoist rope speed (main winch) m/min120At 4 th  layerMax. hoist rope speed(auxiliary winch) m/min100At 2 nd  layerBoom derricking time s40 Boom extending time s80 Slewing speed r/min0~2.2 Traveling specificationsMax. traveling speed km/h78 Max. gradeability %37 Min. turning diameter m≤22 Min. ground clearance mm220 Limits for exhaust pollutants and smokeMeet with related standardsGB3847-2005
GB17691-2005
(National stage III)Oil consumption per hundred kilometers L45 WeightsDeadweight in traveling condition kg31700 Complete vehicle kerb mass kg31570 Front axle load kg6900 Rear axle load kg24800 DimensionsOverall dimensions (L×W×H)mm12700×2500×3450 Longitudinal distance between outriggers m5.36 Transversal distance between outriggers m6.1 Boom lengthm10.4~39.2 Boom angle°-2~80 Jib lengthm8 Offset°0 , 30 ChassisModelZLJ5325Code:ZLJ5325V3ClassII EngineModelWP10.270 Rated power kW/r/min199/2200 Max. output torque N.m/r/min1100/1300 ~1600 ManufacturerChangsha Zoomlion Heavy Industry Science & Technology Development Co., Ltd.
