Oriemac 55 Ton Mini Crawler Crane with Grab Quy55
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- After-sales Service：Free Parts
- Warranty：One Year
- Certification：ISO9001
- Condition：New
- Application：Workshop, Warehouse, Coal Stack, Port, Wharf, Construction Site, Mine
- Anchor：Removable
Base Info
- Model NO.：QUY55
- Structure：Lattice
- Material：Steel
- Type：Unicorn
- Color：Yellow
- Lifting Capacity：55ton
- Boom Length：13~52m
- Engine Power：115kw
- Transport Package：Nude Packing
- Specification：ISO, CE
- Trademark：ORIEMAC
- Origin：Jiangsu, China
- HS Code：8426491000
- Production Capacity：5000,Month
Description
Item Unit Parameter Max. rated lifting capacity Basic boom t 55 Fixed jib t 5 Max. lifting moment t.m 203.5 Boom length m 13~52 Boom luffing angle ° -3~80 Fixed jib length m 9.15~15.25 Max. single line speed for hoist mechanism (no load, at 5th layer ) m/min 121 Max. single line speed for boom luffing mechanism(at 1st layer) m/min 52 Max. swing speed r/min 1.5 Max. travel speed km/h 1.3 Gradeability % 30 Average ground pressure MPa 0.069 Engine power kW 115 Overall weight(main lifting hook,13m boom) t 51 Max. single unit weight for transportation t 31 Max. single unit dimensions for transportation(L×W×H) m 11.5×3.45×3.4
