• Model NO.：QY16C
• Type：Small Crane
• Rated Loading Capacity：16ton
• Engine Model：D6114
• Engine Output：158kw
• Dimension：11990*2500*3350mm
• Power Source：Hydraulic
• Sling Type：Chain
• Transport Package：Suitable Package for Shipment
• Specification：ISO
• Trademark：EVANGEL
• Origin：Jiangsu, China
• HS Code：8402119000
• Production Capacity：100 Sets,Month

ItemUnitParameterEngineModel
 D6114Outline dimensionOverall lengthmm11990Overall widthmm2500Overall heightmm3350Wheel baseAxle 1, Axle 2mm4025Axle 2, Axle 3mm1350MassTotal mass in travel statekg22900

Axle loadAxle 1kg5240Axle 2kg17660Travel performanceTravel speedMax. travel speedkm/h70Min. stable travel speedkm/h4Turning diameterMin. turning diameterm20Min. turning diameter at boom tipm23Min. ground clearancemm270Approach angle(°)21Departure angle(°)10Braking distance (at 30km/h with full load)m9.5Max. grade-ability%24Fuel consumption for 100kmL35PowerEngine rated outputkW/(r/min)158/2200Engine rated torqueN.m/ (r/min)790/1400Engine rated speedr/min2200ItemUnitParameterLifting performanceMax. total rated lifting capacityt16Min. rated working radiusm3Turning radius at turntable tailm≤3.12Max. load momentBase boomkN.m711Fully extended boomkN.m449Fully extended boom + JibkN.m186Outrigger spanLongitudinalm4.6Lateralm5.4Lifting heightBase boomm≥9.9Fully extended boomm≥23.6Fully extended boom + Jibm≥30.8
