Overhead Crane Wire Rope Hoist Single Girder Crane Capacity 32t
Lyfoo Industry Co., Ltd.- Certification：ISO9001: 2000
- Condition：New
- Operation Form：Cabin
- Maximum Lifting Height：25-30m
- Maximum Lifting Weight：<20t
- Main Girder Form：Single Girder
Base Info
- Model NO.：LD
- Type：Single Girder Crane
- Quality：Reliability & Durability
- Types of Electric Hoist：CD, MD
- Crane Motor：Zd52-4,18.5kw and Zd41-4,7.5kw
- Lifting Speed(M/Min)：8, 0.8,8; 7, 0.7,7
- Cross Speed：20 M,Min
- Long Travel Speed：20 M,Min, 5,20 M,Min
- Stepless Speed Control：Available (Variable Frequency Control)
- Electrical System Brand：Siemens,Schneider,Chint
- Affiliate Documents：English Operation Manual, Wiring Diagram
- Power Supply：380V,50Hz,3p, Can Be Customized
- Transport Package：Wooden Box, Plywood
- Specification：A3-A5
- Trademark：Lyfoo industry
- Origin：Xinxiang, Henan, China
- HS Code：84261120
- Production Capacity：15000 Per Year
Description
Crane traveling mechanism Performance parameters 1-5t 10t Traveling Speed (m/min) 20 20 Reduction Ratio (i) 38 38 Motor type YES power 2×0.4 2×0.8 Rotational speed 1200 Working System A5 Power supply 3phrase 380V 50Hz Wheel diameter Ф200 Width of Track 37-70mm
1. The quality of the main girder decides use age and use cost of the crane. "shengqi" consummately adopt European most advanced design and manufacture craft of the main girder. Mail girder wear well , not only let user ease use, but also low maintenance cost.
2. The up camber curve of main girder adopt optimize 4 times curve, ensure traveling have no upgrade resistance when full loading. Overcome the disfigurement of traveling motor overload traveling and trolley slide traveling.
3. End carriage is box girder, and the connection between end carriage and main girder adopt high strength bolt, in order to transport conveniently.
4. Optimize structure design, bearing layout reasonable , bear horizontal force, improve use age of the bearing.
5. The connections of every mechanical part are gears, in order to achieve simple installation and convenient maintenance. The drive wheel group and driven wheel group are all supported on crescent bearing box , convenient for disassembly and adjust.
Warranty:
14 months warranty when products leave the factory, or 12 months warranty after installation and commissioning in addition to the human damage factors.
2 years spare-parts provided for better maintenances.
Professional technical staffs provide installation, commissioning and training services.
Delivery with English user manual, parts manual, product certification and other relevant certificates.
Technical advisory for any time.
