• Model NO.：LT
• Main Girder Form：Double Girder
• Capacity：16t
• Span：7.5 to 31.5m
• Power Supply：380V,50Hz,3p, Can Be Customized
• Sling Type：Wire Rope
• Application：Construction Usage, Workshop Usage
• Hoist Lift Speed：0.8,8 M,Min
• Cross Speed：20 M,Min
• Long Travel Speed：20 M,Min, 5,20 M,Min
• Stepless Speed Control：Available (Variable Frequency Control)
• Electrical System Brand：Siemens,Schneider,Chint
• Transport Package：Electric Parts by Wooden Case, Girder by Fabric
• Specification：ISO, CE
• Trademark：LYFOO
• Origin：China
• HS Code：84261120
• Production Capacity：500units,Month

Basic Info.

Model NO. LT Main Girder Form Double Girder Capacity 16t Span 7.5 to 31.5m Power Supply 380V/50Hz/3p, Can Be Customized Sling Type Wire Rope Application Construction Usage, Workshop Usage Hoist Lift Speed 0.8/8 M/Min Cross Speed 20 M/Min Long Travel Speed 20 M/Min, 5/20 M/Min Stepless Speed Control Available (Variable Frequency Control) Electrical System Brand Siemens/Schneider/Chint Transport Package Electric Parts by Wooden Case, Girder by Fabric Specification ISO, CE Trademark LYFOO Origin China HS Code 84261120 Production Capacity 500units/Month

Product Description

                                 LT type single girder Low-clearance overhead crane
1. Introduction


LT type Low clearance electric single-girder crane is the renew product of "LD", which is a kind of Light cranes that increase the lifting height in low roof workshops. Compared with LD, it makes up for the lifting height defect of old type workshop, whose property is much superior.

Technical parameter

Capacity	3t ~ 50t
Working Span	Up to 31.5m
Lift height	Upon to be requested
Lifting Speed	8m/min
Cross Travel Speed	20m/min
Trolley Travel Speed	20m/min
Work Duty	A5
Controlled by	Pendant/Radio
Power Supply	380v, 3p, 50hz

Advantage
1). First class quality with competitive price
2). Compact design, optimal use of the size of work areas
3). Reasonable structure, favorable performance
4). Control the load easily and position the load exactly
5). Smooth starting and stopping
6). Superior safety and reliability
7). Low noise, commodious cabin and good view
8). Minimum& Easy maintenance, excellent exchangeability for parts and components
9). Saves electricity specifications

Technical Characteristics:
1) Hard-tooth surface of reducer
2) Steel winding drum
3) Imported rope
4) Converter function of adjustable speed without contact or module
5) Intelligence controlling
6) Trinity drive


Cause this is a customized product, please provide us the following information
Capacity?
Lifting Height? (from hook to the ground)
Span?
Local Power-V-Hz-P?

We are the 2nd biggest crane and hoist manufacturer with more than 3000 staffs in China.
Our production line covers: overhead crane, gantry crane, jib crane capacity from 0.5ton to 650ton. Electric wire rope hoist from 0.5ton to 60ton.
We are a reputed company with old customers around the world.
Please do not hesitate to contact us for price.
