Rough Terrain Crane 85ton Zrt850 with Hydraulic Control for Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：>16t
- Shaft Number：3
- Crane Jib：Three-Arm
Base Info
- Model NO.：Zrt850
- Type：Straight Arm
- Transport Package：Nude Package
- Specification：14460*3400*3800 mm
- Trademark：zoomlion
- Origin：China
- HS Code：87051091
- Production Capacity：5000PCS,Year
Description
Type
Ser. No.
Item
Unit
Value
Working performance
1
Max. rated lifting capacity × working radius
kg.m
85000×2.5
2
Max. load moment of main boom
kN.m
2700
3
Max. load moment of main boom (fully extended)
kN.m
1280
4
Max. lifting height of main boom (fully extended)
m
49.8
5
Max. lifting height of jib
m
65.7
Dimensions
6
Overall dimensions (L × W × H)
mm
14460×3400×3800
7
Outrigger spread
(Height × Width)
mm
7380×7300
8
Main boom length
mm
12100 - 47000
9
Jib length
mm
9500 - 16000
10
Boom angle
°
-2 - 80
11
Swing range
360° unlimited swing (Full range)
Working speeds
12
Max. hoist rope speed (Main winch)
m/min
130
13
Min. boom telescoping out time
s
120
14
Min. boom telescoping in time
s
135
15
Min. boom derricking up time
s
46
16
Min. boom derricking down time
s
105
17
Swing speed
r/min
0~2
Hydraulic system
18
Maximum working pressure
MPa
31.5
19
Rate working flow
L/min
280
20
Hydraulic oil tank capacity
L
1000
Gross vehicle mass
21
Gross weight
kg
52000
22
Front weight
kg
27000
23
Rear weight
kg
25000
Driving
24
Max. driving speed
km/h
36
25
Wheelbase
mm
4150
26
Treads
(Front / Rear)
mm
2632
27
Max. gradeability
%
75
