Item | Unit | Value | Remarks |
---|
Max. lifting capacity on heavy duty boom(S)/Radius | Without D and B t × m | 450 × 6 | |
With D and B m | 500 × 12 | |
Length of heavy duth boom(S) | Without D and B m | 24-90 | |
With D and B m | 36-96 | |
Length of light duty boom(SL) | Without D and B m | 48-108 | |
With D and B m | 78-126 | |
Dead weight of crane with basis boom | m | 370 | |
Length of luffing jib(W) | m | 28-84 | |
Max.lifting capacity on luffing jib | Without D and B t × m | 190 × 13 | |
With D and B t × m | 235 × 16 | |
Boom angle when luffing jib is used | . | 65,75,85 | |
Max. length of heavy duty boom with | Without D and B m | 60+72 | |
With D and B m | 84+84 | |
SLHS boom | Main boom m | 84-108 | |
Wind plant jib m | 7 | |
Max.lifting capacity t×m | 126×16 | |
Single rope speed of winches | Hoisting winch 1 | m/min | 0-137 | |
Hoisting winch 2 | 0-137 | |
Main boom derricking winch | 0-50 | |
Luffing jib derricking winch | 0-123 | |
Superlift derricking winch | 0-143 | |
Hoisting winch 3 | 0-109 | |
Slewing speed | rpm | 0-1.0 | |
Traveling speed | km/h | 0-1.0 | |
Gradeability | % | 30 | |
Ground pressure | Mpa | 0.139 | |
Transport dimensions of basic machine | mm | 12180×3345×3205 | Without A-frame |
Max.transport weight of single piece | | 48.6 | |
Engine | Rated power / rotational speed | kW/r/min | 360/1800 | |
Output torque /rotational speed | Nm/r/min | 2200/1300 |
Exhaust emission | | EU Stufe 3A |
Distance between track center × crawler contact length × crawler width | mm | 8000 ×9800×1350 | |
