• Model NO.：XGC800
• Transport Package：Nude
• Trademark：Top Brand
• Origin：Jiangsu, China
• HS Code：8429521200

Basic Info.

Model NO. XGC800 Transport Package Nude Trademark Top Brand Origin Jiangsu, China HS Code 8429521200

Product Description

800 Ton Crawler Crane with Telescopic Boom XGC800
  Feature

XGC800 crawler crane is safe and reliable, convenient to assemble/disassemble and comfort to operate. It is equipped with advanced technologies such as stepless luffing. Under the premise of conventional function satisfaction, it can be used to realize the efficient installation of wind power equipment whose power is less than 3MW.

Item	Unit	Parameter value
Parameter Item	-	XGC800
Operation performance parameter		*
Max. rated lifting capacity for boom	(t)	800
Max. rated lifting capacity for fixed jib	(t)	550
Max. rated lifting capacity for luffing jib	(t)	400
Max. load moment	(t.m)	11000
Max. rated lifting capacity for tower jib	(t)	400
Max. rated lifting capacity for boom single top	(t)	50
Max. rated lifting capacity for special jib	(t)	145
Dimension parameter		*
Boom length	(m)	24~90( heavy type)/ 30~150 ( light type)
Boom luffing angle	(°)	-3~85
Fixed jib length	(m)	12
Tower jib length	(m)	30~102
Max. dimension of single unit in transport state(L×W×H)	(m)	12.5×3.38×3.4
Fixed jib offset angle	(°)	15
Special jib length	(m)	7
Speed parameter		*
Max. single line speed for hoist mechanism	(m/min)	145
Max. single line speed for boom luffing mechanism	(m/min)	2×55
Max. single line speed for jib luffing mechanism	(m/min)	-
Max. slewing speed	(r/min)	0.6
Max. travel speed	(km/h)	1
Grade ability	(%)	30
Mean ground pressure	(MPa)	0.17
Max. single line speed for tower jib luffing mechanism	(m/min)	130
Max. single line speed for superlift luffing	(m/min)	135
Engine		*
Model	-	QSX15
Engine power	(kW)	447
Emission	-	EU III
Mass parameter		*
Overall crane mass	(t)	635(main hook, 24m boom)
Max. mass of single unit in transport state	(t)	53
