130t Heavy Mobile Crawler Crane Hot Sale in Peru Xgc130
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Any
- Max. Lifting Height：76m
- Rated Loading Capacity：130ton
- Certification：ISO9001, CE
- Condition：New
- Warranty：1 Year
Base Info
- Model NO.：XGC130
- Transport Package：Nude
- Trademark：Top Brand
- Origin：Jiangsu, China
- HS Code：8429521200
Description
Basic Info.
Model NO. XGC130 Transport Package Nude Trademark Top Brand Origin Jiangsu, China HS Code 8429521200Product Description
130T Mobile Crawler Crane Hot Sale in Peru XGC130 FeatureInheriting the advantages from the old product, XGC130 crawler crane pays more attention to the improvement of lifting performance, assembly/disassembly and transport convenience and operation comfort.
The system is mature and reliable with complete safety devices. Fitted with advanced technologies including complete assembly and disassembly function, integration transport and etc, the crane's performance is superior to that with other domestic brands in various aspects.
During the initial development period of XGC130 crawler crane, an overall market research is conducted, based on the original three basic working conditions (boom working condition, fixed jib working condition, boom single top working condition), two new working conditions of main hook working condition with fixed jib and fixed jib working condition with main hook are added, hook free fall function is also optionally configured for the hoist mechanism, so as to meet different requirements of the customers.
This crawler crane can be used for farmland construction and water conservancy construction, petrochemical & power engineering, iron and steel, non-ferrous metals, coal and other resource exploration and construction, building construction, municipal construction, port construction and other fields.
| Item | Unit | Parameter |
| Parameter Item | - | XGC130 |
| Operation performance parameter | * | |
| Max. rated lifting capacity for boom | (t) | 130 |
Max. rated lifting capacity for fixed jib | (t) | 18.2 |
Max. rated lifting capacity for luffing jib | (t) | - |
| Max. load moment | (t.m) | 702 |
| Max. rated lifting capacity for tower jib | (t) | - |
Max. rated lifting capacity for boom single top | (t) | 13 |
| Max. rated lifting capacity for special jib | (t) | - |
| Dimension parameter | * | |
| Boom length | (m) | 19~76 |
| Boom luffing angle | (°) | 30~83 |
| Fixed jib length | (m) | 13~25 |
| Tower jib length | (m) | - |
| Max. dimension of single unit in transport state(L×W×H) | (m) | 10.6×3×3.35 |
| Fixed jib offset angle | (°) | 15,30 |
| Special jib length | (m) | - |
| Speed parameter | * | |
| Max. single line speed for hoist mechanism | (m/min) | 110 |
| Max. single line speed for boom luffing mechanism | (m/min) | 75.6/62.6 |
| Max. single line speed for jib luffing mechanism | (m/min) | - |
| Max. slewing speed | (r/min) | 1.3 |
| Max. travel speed | (km/h) | 1.4 |
| Grade ability | (%) | 30 |
| Mean ground pressure | (MPa) | 0.094 |
| Max. single line speed for tower jib luffing mechanism | (m/min) | - |
| Max. single line speed for superlift luffing | (m/min) | - |
| Engine | * | |
| Model | - | SC9DK270G3/QSC |
| Engine power | (kW) | 200/183 |
| Emission | - | National III/EU III |
| Mass parameter | * | |
| Overall crane mass | (t) | 121.1(main hook, 19m boom) |
Max. mass of single unit in transport state | (t) | 32.6 |
