• Model NO.：XGC180
• Trademark：Top Brand
• Origin：Jiangsu, China
• HS Code：8429521200

Basic Info.

Model NO. XGC180 Trademark Top Brand Origin Jiangsu, China HS Code 8429521200

Product Description

 180 Ton Crawling Crane Crawler Crane Xgc180
Features:

• The electro-hydraulic proportional control and outstanding inching performance can meet the precision lifting function.

• Multiple security protection of the three-color lamp sound-light alarm, walking alarm and torque limiter

• Swing mechanism adopts independent closed-type system, imported swing pump and adjustable eccentric swing reducer, which guarantee the smooth swing operation.

• Self-assembly and disassembly function is equipped, which can reduce assembly and disassembly time and mounting cost arised from auxiliary crane.

• Working with main hook under operation with fixed jib (S-2) and working with auxiliary hook under operation with fixed jib (SF-2) are available. With fixed jib installed, the switchover between main hook and auxiliary hook can be realized through the switchover of operation mode in the monitor, and thus the time for boom dismantling and replacement can be saved.

• Excellent anti-rollover stability - It still has a 35% safety margin at rated load.

• The electrical system uses flexible cables featuring corrosion, oil stain and UV resistance and electrical connectors featuring superior waterproof performance to prolong its service life.

Parameter

Item	Unit	Data
Basic boom	t	180
Fixed jib	t	33.5
Luffing jib	t	50
Max.load moment	t.m	1000.8
Boom length	m	19-82
Boom working condition	.	30-83
Tower jib working condition	.	30-85
Fixed jib working condition	.	30-85
Fixed jib length	m	13-31
Luffing jib length	m	20-59
Winch max.single line speed(no load,at 5th layer)	m/min	120
Boom elevating gear max.single line speed (at 1th layer)	m/min	2×28.4
Max.swing speed	r/min	1.5
Max.travel speed	km/h	1.3
Grade-ability	%	30
Ground pressure	MPa	0.105
Engine output power	kW	250
Total vehicle mass(main hook block,19m boom)	t	175
Single unit mass for transport	t	37
Single unit dimension for transport(L×W×H)	m	11.5×3.0×3.3
