China 10t Lifting Capacity Fold Crane 6X4 Hot Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- Certification:CE, ISO9001
- Condition:New
- Maximum Lifting Height:20-25m
- Maximum Lifting Weight:2-4t
- Shaft Number:3
- Crane Jib:Three-Arm
Base Info
- Model NO.:ZZ1257N5247W
- Type:Folding
- Transport Package:Roro
- Specification:11250*2600*3850mm
- Trademark:SINO
- Origin:Shandong
- Production Capacity:1000 Pieces,Per Month
Description
Chassis Model
ZZ1257N5247W
Driving Type
LHD (RHD is optional)
Cabin
HW76, with one sleeper and two seats, double arm windscreen wiper system with three speeds, damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, air conditioner, with transverse stabilizer, with four piont support floating suspension+shock absorber.
Engine
Make: SINOTRUK
Diesel 4-stroke direct injection diesel engine
Engine model: WD615.69, Euro 2, 336 HP
6-cylinder in-line with water cooling, turbo-charging and intercooling
Displacement: 9.726 L
Transmission
HW19710, 10F & 2R with PTO
Ratio:14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34, 1.00, 13.91(R1), 3.18(R2)
Steering
ZF power steering, modol ZF8118, hydraulic steering with power assitance
Front Axle
HF9,1x9000 KGS
Steering with doubleT-cross section beam
Rear Axle
HC16, 2x16000 KGS
Pressed axle housing, central single reduction with hub reduction,with differential locks between wheels and axles.
Ratio:4.42
Propeller Shaft
Double universal joint propeller shaft with gear-shaped coupling flange
Chassis
Frame: Uprofile parallel ladder frame with section of 300x80x8mm,reinforced subframe all cold riveted cross members
Front suspension:10 semi elliptic leaf spring, hydraulic telescopic double-action shock absorbers and stabilizer
Rear suspension:12 leaf semi elliptic springs, bogie spring and stabilizer
Brake
Service brake: dual circuit compressed air brake
Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels
Auxiliary brake: engine exhaust brake
Electrics
Operating voltage: 24 V, negative grounded
Starter: 24 V, 5.4 Kw
Alternator: 3-phase, 28 V, 1500 W
Batteries: 2 x 12 V, 165 Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tyres
315/80R22.5, tubless tires with one spare tire
Fuel Tank
400L
Cargo Body
Size: 7200*2300*800 mm;
Crane: 10 tons; XCMG Brand
Overall Dimension
11250*2600*3850mm
