• Model NO.：QY25K-II
• Shaft Number：,
• Crane Jib：,
• Type：Straight Arm
• L*W*H：12650*2500*3380mm
• Wheelbase：5775mm
• Engine Rated Power：213kw
• Engine Rated Torque：1160n.M
• Max. Travel Speed：75km,H
• Max. Gradeability：30%
• Maximum Lifting Moment：1010kn.M
• Transport Package：Nude
• Specification：29400kg
• Trademark：SINOMADA
• Origin：China
• HS Code：8426411000
• Production Capacity：100units,Month

Product Parameters

Parameter item

QY25K -II

Size parameters

*

Overall length (mm)

12650

Overall width (mm)

2500

Overall height (mm)

3380/3290

Wheelbase (mm)

4425+1350

Wheel base (mm)

Front wheel 2074/rear wheel 1834

Weight parameter

*

Total mass in driving state (kg)

29400

Axle load (kg)

Front axle 6200/rear axle 23200

Dynamic parameters

*

engine model

WD615.329SC8DK280Q3

Engine rated power (kw/(r/min))

213/2200;206/2200

Engine rated torque (Nm/(r/min))

1160/1100-16001112/1400

Driving parameters

*

Driving

*

Maximum driving speed (km/h)

75

Minimum stable driving speed (km/h)

2.9

Turn

*

Minimum turning diameter (m)

21.5

Minimum turning diameter of arm head (m)

-

Maximum grade(%)

30

Minimum ground clearance (mm)

275

Approach angle (°)

16

Departure angle (°)

13

Braking distance (m)

10

Fuel consumption per hundred kilometers (L)

37

Main performance parameters

*

Maximum rated total lifting capacity (t)

25

Minimum rated amplitude (m)

3

Maximum lifting moment of basic boom (kN·m)

1010

Turntable tail turning radius (mm)

3065

Outrigger

*

Longitudinal (m)

5.14

Horizontal (m)

6

Lifting height

*

Basic arm (m)

10.8

Longest main boom (m)

34.19

Longest main boom + secondary boom (m)

42.3
