• Model NO.：QY75K
• Shaft Number：,
• Crane Jib：,
• Type：Straight Arm
• L*W*H：14650*2800*3880
• Wheelbase：7665mm
• Engine Rated Power：276kw
• Engine Rated Torque：1500,1100-1600n.M
• Max. Driving Speed：80km,H
• Max. Gradeability：37%
• Max. Lifting Height：64.5m
• Transport Package：Nude
• Specification：48000kg
• Trademark：SINOMADA
• Origin：China
• HS Code：8426411000
• Production Capacity：100units,Month

Product Parameters

Parameter item

QY75K

Size parameters

*

Overall length (mm)

14,650

Overall width (mm)

2800

Overall height (mm)

3880

Wheelbase (mm)

1500+4665+1500

Wheel base (mm)

2380/2380/2300/2300

Weight parameter

*

Total mass in driving state (kg)

48000

Axle load (kg)

1 and 2 axis 12000 3 and 4 axis 12000

Dynamic parameters

*

engine model

D10.38A-40

Engine rated power (kw/(r/min))

276/2200

Engine rated torque (Nm/(r/min))

1500/1100~1600

Driving parameters

*

Driving

*

Maximum driving speed (km/h)

80

Minimum stable driving speed (km/h)

2.5~3

Turn

*

Minimum turning diameter (m)

20

Minimum turning diameter of arm head (m)

-

Maximum grade(%)

37

Minimum ground clearance (mm)

427

Approach angle (°)

19

Departure angle (°)

15

Braking distance (m)

≤10

Fuel consumption per hundred kilometers (L)

48

Main performance parameters

*

Maximum rated total lifting capacity (t)

75

Minimum rated amplitude (m)

3

Maximum lifting moment of basic boom (kN·m)

2969

Turntable tail turning radius (mm)

4330

Outrigger

*

Longitudinal (m)

6.4

Horizontal (m)

7.6

Lifting height

*

Basic arm (m)

12.6

Longest main boom (m)

47

Longest main boom + secondary boom (m)

64.5
