12000kg New Telescopic Boom Truck Crane 12 Ton Lifting Crane Price Xct12L4
Newindu Construction Engineering (Shanghai) Co., Ltd.- After-sales Service：Online Service, Spare Parts
- Warranty：2 Years
- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：11-13t
Base Info
- Model NO.：XCT12L4
- Shaft Number：3
- Crane Jib：Five-Arm
- Type：Folding
- Max. Lifting Height：65m
- Hydraulic Parts：Telescopic Boom Mobile Crane Made
- Max. Lifting Load：12t
- Span：7.6m
- Total Weight in Travel：16000kg
- Transport Package：Nude Package
- Specification：12t
- Trademark：China
- Origin：Jiangsu, China
- Production Capacity：100pieces,Month
Description
Category
Item
Unit
Parameter
Main performance
Max. total rated lifting capacity
t
12
Min. rated working radius
m
3
Turning radius at turntable tail
Counterweight
mm
2570
Auxiliary winch
mm
2910
Max. load moment
Base boom
t.m
48.25
Fully-extended boom
t.m
27.60
Outrigger span (fully- extended)
Longitudinal
m
4.57
Lateral
m
5.5
Hoist height
Base boom
m
9.5
Fully-extended boom
m
30.9
Fully-extended boom + Jib
m
38.1
Boom length
Base boom
m
9.45
Fully-extended boom
m
30.5
Fully-extended boom + Jib
m
30.5+7
Jib offset angle
°
0
Working speed
Elevating time
Boom raising
s
≤38
Telescoping time
Fully extended
s
≤58
Max. slewing speed
r/min
3
Outrigger extending and retracting time
Outrigger beam
Extending Simultaneously
s
≤20
Retracting Simultaneously
s
≤15
Outrigger jack
Extending Simultaneously
s
≤25
Retracting Simultaneously
s
≤20
Hoisting speed (single line, 4th layer)
Main winch
m/min
138
Auxiliary winch
m/min
138
Noise
Exterior noise level
dB
(A)
≤122
Noise level at seated position
dB
(A)
≤90
