Zoomlion 2020 New 100ton Rough Terrain Crane with Good Price
Sinomada Heavy Industry (Changsha) Co., Ltd.- Certification:CE, ISO9001
- Condition:New
- Maximum Lifting Height:>40m
- Maximum Lifting Weight:>16t
- Shaft Number:3
- Crane Jib:Five-Arm
Base Info
- Model NO.:RT100
- Type:Folding
- Main Boom Length:10800-34000mm
- Jib Length:10000-17000mm
- Swing Speed:0-1.5r,Min
- Rated Working Pressure:30MPa
- Rated Working Flow:500L,Min
- Hydraulic Oil Tank Capacity:1200L
- Complete Vehicle Kerb Mass:65000kg
- Front Axle Load:33200kg
- Rear Axle Load:31800kg
- Max. Traveling Speed:24,15km,H
- Transport Package:Container,RO-RO
- Specification:14247*3620*3960mm
- Trademark:ZOOMLION
- Origin:China
- HS Code:8705109200
- Production Capacity:100,Month
Description
Work performanceMax. rated lift capacity × work radius kg.m 100000×3.0 Max. load moment of basic boom kN.m 3339 Max. load moment of fully extended main boom kN.m 1388 Max. lift height of fully extended main boom m 45.6 Max. lift height of jib m 63 Dimensions Overall dimensions(L×W×H) mm 14247×3620×3960 Outrigger spread (L×W) mm 8000×7900 Main boom length (Fully retracted fully extended) mm 10800-34000 Jib length (Jib section 1,jib sections 1+2) mm 10000-17000 Boom angle ° -3 - 78 Swing range ° 360 360° unlimited swing(Full range) Work Speeds Max. hoist rope speed (Main winch) m/min 126 Min. boom extend time s 170 Min. boom retract time s 158 Min. boom derrick up time s 82 Min. boom derrick down time s 69 Swing speed r/min 0-1.5 Hydraulic system Rated work pressure MPa 30 Rated work oil flow L/min 500 Hydraulic oil tank capacity L 1200 Mass Complete vehicle mass kg 65000 Front axle load kg 33200 Rear axle load kg 31800 Travel Max. travel speed (Forwarsd / backwards) km/h 24/15 Wheelbase mm 4600 Treads (Front / rear) mm 2860
