China Top Brand Zoomlion 30t Rough Terrain Crane Hot Selling

Sinomada Heavy Industry (Changsha) Co., Ltd.

Certification：CE, ISO9001
Condition：New
Maximum Lifting Height：>40m
Maximum Lifting Weight：>16t
Shaft Number：3
Crane Jib：Five-Arm

Base Info

Model NO.：ZRT300
Type：Folding
Main Boom Length：10700~35000mm
Jib Length：8000mm
Swing Speed：0-2.5r,Min
Rated Working Pressure：30MPa
Rated Working Flow：300L,Min
Hydraulic Oil Tank Capacity：500L
Complete Vehicle Kerb Mass：28300kg
Front Axle Load：14600kg
Rear Axle Load：13700kg
Max. Traveling Speed：45km,H
Transport Package：Container,RO-RO
Specification：14247*3620*3960mm
Trademark：ZOOMLION
Origin：China
HS Code：8705109100
Production Capacity：100,Month

Description

ItemUnitValueWork performanceMax. rated lift capacity × work radius

lb.ft

kg.m

66138.7×9.8

30000×3

Max. load moment of basic jib

lbf.ft

kN.m

708480

960

Max. load moment of max. length main boom

lbf.ft

kN.m

487080

660

Max. lifting height of max. length main boom m37.2Max. lifting height of jibm45DimensionsOverall dimensions(L×W×H)mm13600×2610×3600Outrigger spread(L×W)mm6700×6300Main boom length (Fully retracted-fully extended)

in

mm

421.3~1378

10700~35000

Jib lengths (Fully retracted-fully extended)

in

mm

31

8000

Boom angle°-2 -80Swing range°360°unlimited swing(Full range)Work SpeedsMax. hoist rope speed (Main winch)m/min140Min. boom telescoping out times67Min. boom telescoping in times50Min. boom derrick up times35Min. boom derrick down times50Swing speedr/min0-2.5Hydraulic systemRated working pressureMPa22Rated working flowL/min300Hydraulic oil tank capacityL580MassComplete vehicle kerb masskg28300Front axle loadkg14600Rear axle loadkg13700DrivingMax. travel speedkm/h45Wheelbasemm3880Treads (Front / rear)mm2214Max. gradeability%51
China Top Brand Zoomlion 30t Rough Terrain Crane Hot Selling

Company Profile
China Top Brand Zoomlion 30t Rough Terrain Crane Hot Selling
