Shipyard Heavy Duty Double Girder Beam Overhead Gantry Crane 10t for Ship Building Construction
Nucleon (Xinxiang) Crane Co., Ltd.- After-sales Service：Technical Advisory of Installation & Commissioning
- Warranty：12 Month Warranty After Successful Installation
- Certification：CE, ISO9001, ISO14001
- Condition：New
- Maximum Lifting Weight：50-100t
- Maximum Lifting Height：20-25m
Base Info
- Model NO.：MG
- Operation Form：Air Operation+Ground Operation
- Type：Common Gantry Crane
- Main Girder Form：Double Girder
- Load Capacity：up to 100 Ton
- Span：up to 50 Meters (Cantilever Included)
- Height of Lift：up to 20 Meters
- Control：Wireless Radio Remote,Cabin Operation
- Power Supply：380~480V, 50~60Hz, 3phase
- Hoisting Speed：1~10 M,Min (VFD)
- Hoist Travel Speed：3~30 M,Min (VFD)
- Crane Travel Speed：4~40 M,Min (VFD)
- Duty Class：A5 (ISO)
- Permitted Wind Speed：Less Than 12 M,S (Outdoor)
- Cantilever：Available at Either or Both Gantry Side
- Lead Time：Within 30 Days
- Installation：Video Tutorial, Site Installation & Commissioning
- Random Files：Operation & Maintenance Manual, Wiring Diagram
- Spare Parts：Provide Random Spares for Two Year Maintenance
- Transport Package：Wooden Case, Waterproof Film, Steel Pallet
- Specification：Single winch crab,Tandem Control twin winch crabs
- Trademark：Nucleon Crane
- Origin：Henan, China
- HS Code：8426112000
- Production Capacity：600 Sets Per Annum
Description
