• Model NO.：L250-20
• Type：Under-Slewing Crane
• Max. Jib Length：60m
• Hoisting Capacity at Jib Tip：2.71ton
• Hoisting Mechanism：H75FL100-710d
• Hoisting Power：75kw
• Rope Capacity：710m
• Slewing Mechanism：Hvv75f1.130c, Hvv145f2.130c
• Slewing Power：2*7.5kw
• Trolleying Mechanism：L45FL50
• Trolleying Power：45kw
• Color：Green
• Transport Package：Container,RO-RO
• Specification：60m
• Trademark：ZOOMLION
• Origin：China
• HS Code：8426200000
• Production Capacity：100,Month

 Rated liftingmoment (t.m)250 Max. lifting    height (m)Free-standing    stationary crane52.85Anchored crane165.35Working radius    (m)     Max. working    radius   60Min. working    radius    3.3Max. lifting    capacity (t)20Hoisting    mechanism Rope    fallα=2α=4Speed (m/min)0~400~800~1000~200~400~50Lifting weight    (t)1052.520105Power (kW)75Slewing    mechanismSpeed (m/min)0~0.61Power (kW)2×7.5kWTrolleying    mechanismSpeed (m/min)2.2 (15°~85°)Power (kW)45
