• Model NO.：Ztc550r532
• Type：Straight Arm
• Max. Lifting Height of Basic Boom：12.6m
• Max. Lifting Height of Main Boom：43.6m
• Max. Load Moment of Basic Boom：2009kn.M
• Max. Rated Lifting Capacity：55000kg
• Max. Lifting Height of Jib：59.5m
• Transport Package：Nude Packing
• Specification：13700*2800*3650mm
• Trademark：non
• Origin：China
• HS Code：87051092
• Production Capacity：1000 Unit Per Year

ItemUnitValueRemarksWorking    performanceMax.    rated lifting capacitykg55000Max.    load moment of basic boomkN.m1568Max.    load moment of main boom(fully extended)kN.m940.8Max.    load moment of basic boomm11.8Max.    lifting height of main boomm44Max.    lifting height of jibm60Working    speeds            Max.    hoist rope speed(Main winch)m/min135Max.    hoist rope speed(Auxiliary winch)m/min120Boom    demrricking up times45Boom    demrricking up times95Slewing  speedr/min0    -2.2Driving    parametersMax.    driving  speedkm/h74Max.    gradeability%40Turning    diameterm≤24Min.  ground clearancemm260Oil    consumption per hundred kilometersL40MassDeadweight    in driving conditionkg39000Complete    vehicle kerb masskg38805Front    axle loadkg13000Rear    axle loadkg26000DimensionsOverall    dimensions(L×W×H)mm13530×2600×3700Outrigger    spread(L)m7.30Outrigger    spread(W)mFully    extended:5.95,
     Intermediately    extended:4.8Tail    slewing radiusmm3690Main    boom lengthm11.2    - 44.0Boom    angle°-2    - 80jib    lengthm9.5, 16.0Offset°0,15,30
