• Model NO.：Ztc250r531
• Type：Straight Arm
• Max. Rated Lifting Capacity：25000kg
• Max. Load Moment of Basic Boom：960kn.M
• Max. Lifting Height of Jib：47.8m
• Max. Gradeability：42%
• Jib Length：8m
• Transport Package：Nude Packing
• Specification：12600*2500*3450mm
• Trademark：non
• Origin：China
• HS Code：87051092
• Production Capacity：1000 Unit Per Year

ItemUnitValueRemarksWorking    performanceMax.    rated lifting capacitykg25000Max.    load moment of basic boomkN.m960Max.    load moment of main boom(fully extended)kN.m598Max.    load moment of basic boomm10.9Max.    lifting height of main boomm40.2Max.    lifting height of jibm47.8Working    speeds           Max.    hoist rope speed(Main winch)m/min135Max.    hoist rope speed(Auxiliary winch)m/min135Boom    demrricking up times25Boom    telescoping out times82Slewing  speedr/min0    -2.7Driving    parametersMax.    driving  speedkm/h85Max.    gradeability%42Turning    diameterm≤20Min.  ground clearancemm250Oil    consumption per hundred kilometersL28MassDeadweight    in driving conditionkg30600Complete    vehicle kerb masskg30470Front    axle loadkg6500Rear    axle loadkg24100DimensionsOverall    dimensions(L×W×H)mm12600×2500×3450Outrigger    spread(L)m5.40Outrigger    spread(W)mFully    extended:6.2,
     Intermediately    extended:4.25Tail    slewing radiusmm3265Main    boom lengthm10.2    - 40.0Boom    angle°-1    - 80jib    lengthm8.0Offset°5,17,30
