• Model NO.：XCT90
• Min. Ground Clearance：367mm
• Max. Grade Ability：45%
• Transport Package：Comply with Export Packaging Requirment
• Specification：13985*2780*3990mm
• Trademark：XCMG
• Origin：Xuzhou, Jiangsu, China
• HS Code：87059091
• Production Capacity：10000,Year

CategoryItemUnitParameter



DimensionOverall lengthmm13985Overall widthmm2780Overall heightmm3990Wheel basemm2000+4000+1500Trackmm2354×2354/2291×2291Front overhangmm2525Rear overhangmm2310


WeightTotal mass in travel configurationkg48000

Axle loadAxle 1kg12000Axle 2kg12000Axle 3kg12000Axle 4kg12000

PowerChassis engine model MC11.40-50WP12.375E50Engine rated powerkW/(r/min)297/1900276/1900 Engine rated torque N.m/(r/min) 1900/1000~1400 1800/1000~1400







TravelTravel speedMax. travel speedkm/h90Min. travel speedkm/h1.7~3
Turning diameterMin. turning diameterm20Min. turning diameter at boom tip m 25.2Min. ground clearancemm367Approach angle°21Departure angle°15Braking distance (at 30 km/h )m≤10Max. grade ability%45Fuel consumption per 100 kmL45
[Product Picture]





[Company Information]

[FAQ]
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted.
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC.
3: What about the delivery time?
A: 7-30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
