• Model NO.：QY25K-II
• Shaft Number：3
• Crane Jib：Four-Arm
• Type：Straight Arm
• Max. Lifting Capacity：25t
• Min. Working Radius：3000mm
• Max. Lifting Torque：1010kn.M
• Longest Boom Lifting Height：34.19m
• Engine：Shangchai Caterpillar
• Transport Package：Container Roro Bulk Break Shipment
• Specification：12650*2500*3380mm
• Trademark：China
• Origin：Jiangsu
• HS Code：8705109100
• Production Capacity：50PCS,Month

                  ItemparameterUnitDimensionsTotal length12990mmTotal  width2500mmTotal  height3430mmWeightOperating weight29000KgFront axle load   6970KgRear axle load22030KgPowerEngine modelSC8DK260Q3 Engine power ratings192/2200Kw(r/min)Engine torque  ratings1000/1400N.m(r/min)TravelMax.travel speed75Km/hMax. turning diameter20mMax. ground clearance272mmApproach angle16.Departure angle13.Max. grade ability30%Fuel consumption of 100km40Ldriving performanceMax. lifting capacity25tMin. working radius3000mmTurning radius at swing table tail3.45mMax. lifting torque1010Kn.mBase boom lifting height10.85mlongest boom lifting height34.19mlongest boom lifting height with secondary arm42.3mOutrigger longitudinal distance span5.0mOutrigger lateral distance span6mWorking speedElevation duration for secondary boom75sElevation duration for fully extended boom 100sMax. rotation speed3.0r/minMax. speed for main winch85/120m/minMax. speed for auxiliary winch85/120m/min





Our company
We, Newindu E-Commerce (Shanghai) Co., Ltd, are professional in construction machinery for nearlly 10 years,exporting with good quality and low price, having excavator,truck crane,bulldozer,wheel loader,motor grader,drilling rig,dump truck,road roller,forklift,reach stacker,and also including the spare parts,etc.
