• Model NO.：QUY350
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Folding
• Hydraulic Parts：Telescopic Boom Mobile Crane Made
• Operate System：Computer Board Control
• Fully Extended Boom：128.9meters
• Fully Extended Boom+Jib：59.4meters
• Operation Weight：300
• Total Weight in Travel：49.3ton
• Rated Lifting Moment：240 Kn*M
• Rated Loading Capacity：280
• Application：Construction
• Span：1.3m-3.5m
• Transport Package：Bulk Vessel
• Specification：150
• Trademark：Chinese Brand
• Origin：China
• HS Code：9480092
• Production Capacity：40

ItemUnitValueMax. lifting load/ working radius/
boom lengthStandardt × m×m350/5/18Superliftingt × m×m350/5.5/30Main boom lengthStandardm18~84Superliftingm30~84Light-duty main boom lengthStandardm24~102Superliftingm42~120Fixed fly jib lengthm12Max. lifting load of fixed fly jibt80Offset angle of fixed fly jib°10,25,40Main boom length under
fixed fly jib operating conditionStandardm54~96Superliftingm54~102Luffing fly jib lengthStandardm24~66Superliftingm24~84Max.lifting load of luffing fly jibStandardm140Superliftingm160Main boom working angle under luffing fly jib operating condition°65,75,87Main boom length under
luffing fly jib operating conditionStandardm24~60Superliftingm30~84Main boom length under
luffing fly jib operating condition
+ Max. length of fly jibStandardm54+66,60+42Superliftingm84+84Speed of drum single layer ropeMain hoist on the 8th rope layerm/min135Auxiliary hoist on the 7th rope layerm/min120Main luffing gear on the 7th rope layerm/min50×2Luffing jib derricking on 7th rope layerm/min120Superlifting derricking on 7th rope layerm/min120Max. slewing speedrpm1.0Max traveling speedkm/h1.2Gradeability%20Ground PressureMPa0.115With deadweight of basic boomt280Max. weight of single componentsWith mast, wincht61 With mast, winchwithout mast, wincht43 without mast, winchenginemodel QSM11Power/rotational speedkW/rpm298/2100Torque/rotational speedNm.rpm1898/1400
Pictures








Company Information
Newindu Construction Engineering (Shanghai) Co., Ltd. is professional in construction machinery for nearly 12 years, exporting with good quality and low price, having excavator, truck crane, bulldozer, wheel loader, motor grader, drilling rig, dump truck, road roller, forklift, reach stacker, and also including the spare parts, etc.
