Oriemac 2ton Lifting Capacity Mini Crawler Spider Crane with CE
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Max. Lifting Height：5.5m
- Rated Loading Capacity：1ton
- Certification：ISO9001, CE
- Condition：New
- Warranty：1 Year
- Model：Mini Crawler Crane
Base Info
- Model NO.：SPT199
- Lifting Capacity：2.0t*1.4m
- Maximum Radius：5.93m*0.2t
- Max.Lifting Height：6.6m*0.8ton
- Max.Lifting Depth：10-40m
- Hook up Speed：10 M,Min (2 Strands)
- Crane Arm Length：2.35m-6.2m
- Walking Speed：0-3.2km , H
- Vehicle Weight：1650kg
- Transport Package：Wooden Case or Nude Package
- Specification：2500*650*1460mm
- Trademark：ORIEMAC
- Origin：China
- HS Code：8426491000
- Production Capacity：100 Units,Month
Description
Model
SPT199
Capacity
2.0t×1.4m
Working radius
5.93m×0.20t
Ground lifting height
6.60m×0.80t
Underground lifting height
10m-4 fall 20m-2 fall 40m-1 fall
Winch device
Hook speed
0-6m/min (4 fall)
Rope type
Φ8mm×45m
Telescopic system
Boom form
4 section boom, hexagonal box construction
Boom length/Time
2.35m-6.20m/30sec
Up and downs
Boom angle/Time
0-78°/20sec
Slew system
Slew angle/Speed
0-360°(continuous)/60sec
Outrigger
Outrigger active form
Manual + Hydraulic
Maximum extended dimensions (mm)
3420(Length)X2960(Front)X3125(Back)
Traction system
Walking way
Hydraulic motor drive
Walking speed
0-2km/h
Grade ability
20°(36%)
Ground length×width
1040mm×180 mm
Ground pressure
43kpa(0.44 kgf/cm²)
Electric motor
Voltage
AC380V(Optional)
Power/Speed
3kw/1440 min-1
Sound level
Rated speed ≤75dB(A) (1m)
Diesel engine
Model
KD440 (KOHLER)
Type/Displacement
Single cylinder air cooled/0.441L
Rated output
8kw/3600 min-1
Starting method
Electric
Operating temperature
-5°C~40°C
Fuel/Volume
Diesel/5L
Battery capacity
12v 36AH
Specific fuel consumption
240g/kW-h
Sound Level
Rated speed ≤80dB(A) (7m)
Applied regulation/Altitude
EPA-Tier4,EC stage V /1200m
Operate system
Type of operation
Diesel engine, Electric motor, Radio remote control, Searcher hook, Black rubber track, Intelligent display screen, Moment limiter, Over hoist alarm and automatic stop device, Three-winding alarm and automatic stop device, Automatic hook stow, Outrigger position detector device, Outrigger off the ground alarm and automatic stop device, Slinging rope detachment protector, EMO switch, Three color lamp, Remote control lamp, Voice prompt, Walking/Outrigger/Boom three-mode interlock system, Data records
Optional configuration
Glass suction, White rubber track, Manual fly jib, Single-man basket, Outrigger pads
