Oriemac Mobile Crane 4 Ton Mini Spider Crawler Crane Spt399
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Max. Lifting Height：12.9m
- Rated Loading Capacity：4ton
- Certification：ISO9001, CE
- Condition：New
- Warranty：1 Year
- Model：Spt399 Mini Crawler Crane
Base Info
- Model NO.：SPT399
- Lifting Capacity：4.0t*2.0m
- Maximum Radius：12.2m*0.3t
- Max.Lifting Height：12.9m*0.9ton
- Max.Lifting Depth：16-64m
- Hook up Speed：10 M,Min (2 Strands)
- Crane Arm Length：3.7m-12.5m
- Walking Speed：0-3.2km , H
- Vehicle Weight：4000kg
- Transport Package：Wooden Case or Nude Package
- Specification：4350*1200*1750mm
- Trademark：ORIEMAC
- Origin：China
- HS Code：8426491000
- Production Capacity：100 Units,Month
Description
Model
SPT399
Capacity
4.0t×2.0m
Working radius
12.2m×0.30t
Ground lifting height
12.9m×0.90t
Underground lifting height
16m-4 fall 32m-2 fall 64m-1 fall
Winch device
Hook speed
0-10m/min (4 fall)
Rope type
Φ8mm×72m
Telescopic system
Boom form
5 section boom, hexagonal box construction
Boom length/Time
3.7m-12.5m/35sec
Up and downs
Boom angle/Time
0-80°/15sec
Slew system
Slew angle/Speed
0-360°(continuous)/60sec
Outrigger
Outrigger active form
Manual + Hydraulic
Maximum extended dimensions (mm)
4580(Length)X4380(Front)X 4450(Back)
Traction system
Walking way
Hydraulic motor drive,2 speed
Walking speed
0-2.5km/ h
Grade ability
20°(36%)
Ground length×width
1750mm×300 mm
Ground pressure
38.5kpa(0.39 kgf/cm²)
Electric motor
Voltage
AC380V(Optional)
Power/Speed
5.5kw/1440 min-1
Sound level
Rated speed ≤75dB(A) (1m)
Diesel engine
Model
3TNV80F(YANMAR)
Type/Displacement
3 Cylinder water cooled/1.266L
Rated output
14.6kw/2400 min-1
Starting method
Electric
Operating temperature
-5°C~40°C
Fuel/Volume
Diesel/40L
Battery capacity
12v 45AH
Specific fuel consumption
272g/kW-h
Sound Level
Rated speed ≤84dB(A) (1m)
Applied regulation/Altitude
EPA-Tier4,EC stage V/1200m
Operate system
Type of operation
Diesel engine, Electric motor, Radio remote control, Searcher hook, Black rubber track, Intelligent display screen, Moment limiter, Over hoist alarm and automatic stop device, Three-winding alarm and automatic stop device, Automatic hook stow, Outrigger position detector device, Outrigger off the ground alarm and automatic stop device, Slinging rope detachment protector, EMO switch, Three color lamp, Remote control lamp, Voice prompt, Walking/Outrigger/Boom three-mode interlock system, Data records
Optional configuration
Glass suction, White rubber track, Manual fly jib, Hydraulic fly jib, Single-man basket, Outrigger pads
