• Model NO.：30ton
• Type：Straight Arm
• Hook Capacity：30000kgs
• Tyre Size(Standard)：18.00r25
• Tyre Pressure：785kpa
• Hoist Rope Length：220m
• S/N：051466
• Travelled Distance：6912mm
• Jib Length：9-14.5m
• Max Lifting Height：54.5m
• Transport Package：Bulk Vessel,Fr
• Specification：truck crane
• Trademark：tadano
• Origin：Japan
• HS Code：8705109100
• Production Capacity：5units Per Month

Dimension

Unit



Overall length

mm

12570

Overall width

mm

2500

Overall height

mm

3390

Weight



Total weight in travel

kg

32400

Front axle load

kg

7000

Rear axle load

kg

25400

Power



Engine model



mitsubishi 6cylinders engine

Engine rated power

kW/(r/min)

206/2200

213/2200

Engine rated torque

N.m/(r/min)

1112/1400

1160/1400

Travel



Max. travel speed

km/h

80

Min. turning diameter

m

22

Min. ground clearance

mm

291

Approach angle

°

19

Departure angle

°

13

Max. grade ability

%

40

Fuel consumption for 100km

L

40

Main performance



Max. rated total lifting capacity

t

30

Min. rated working radius

mm

3000

Turning radius at turntable tail

m

3.065

Max. lifting torque

kN.m

1025

Base boom

m

10.6

Fully extended boom

m

40.4

Fully extended boom+ jib

m

48.7

Longitudinal outrigger span

m

5.85

Lateral outrigger span

m

6

Working speed



Boom luffing time

s

68

Boom full extension time

s

150

Max. swing speed

r/min

2.5

Max. speed of main winch (single rope) (no load)

m/min

120

Max. speed of aux. winch (single rope) (no load)

m/min

120

KNOW MORE ABOUT US ===========================
Our company do win-win business with good exporting business reputation which provide used /second hand construction mahcinery, for instance used wheel loaders,used excavators, used motor graders , used bulldozers ,road rollers ,mixer trucks ,dump trucks ,cranes ,forklifts ,tractor trucks ,and pump trucks . The above is the hot sale line for global market with the following advantage .

      1>Original parts and good working condition;
      2>Low working hours and well-test service for machinery
      3>Strong engine power .
      4>Complete accessory and no oil leaking;
      5>Competitive price ,price is negotiatable to some degree .
      6>Good After-sales Service!

WELCOME U CONTACT US AND VISIT US TO INSPECT MACHINERY ,WE CAN OFFER THE PRE-SALE RESEPTION SERVICES .,
      1) Pick you up at airport;
      2) Reservate hotel for you;
      3) Guide u visit the tourist points in shanghai when u are free after finish business .

BUSINESS LINE =========================
Used Truck Crane
1. KATO: NK250E, NK350E, NK400E-3, NK500E, NK550E
2. TADANO: TL250E, TL300E, TG500E, TG550E, TG650E
Used Crawler Crane
1. HITACHI KH125 35T, KH180 50T, KH700 150T
2. KOBELCO 7045 50T, 5100 100T, 7150 150T
3. SUMITOMO LS118 50T, LS238 100T, LS248 100T
Used Excavator
1. Used hitachi excavator: EX100WD, EX120, EX200-1, EX200-2, EX200-3, EX200-5, EX350, ZAXIS200, ZAXIS230
2. KOMATSU PC60, PC120, PC130-7, PC200, PC210, PC220
3. CAT CAT312B, CAT320B, CAT320C, CAT325B, CAT330B, CAT 330C
4. HYUNDAI, DAEWOO, KEBOLCO, SIMITOMO, etc
Used Wheel Loader
1. KOMATSU WA300, WA350, WA360, WA380, WA400, WA470
2. CAT CAT936E, CAT950B, CAT950F, CAT966D, CAT 966E, CAT966F
3. KAWASAKI KLD65Z, KLD70, KLD70B, KLD80, KLD85, KLD85Z
4. TCM TCM230, TCM870,TCM75B
Used Bulldozer
1. CATERPILLAR D6D, D6H, D7H, D7G, D8 K, D8N, D9L
2. KOMATSU D75A-1, D85A-18, D85A-21, D155-1, D155-2, D355, D375
Used Motor Grader
1. CAT 12G, 120G, 14G, 140H
2. KOMATSU GD511A, GD605R, GD623A
Road roller
1. DYNAPAC CA25, CA30 (weight: 8T-14T)
2. BOMAG BW213D-2, BW217D-2, BW219D-2
TRUCK
DUMP TRUCK :ISUZU ,MITSUBISHI ,NISSAN-UD ,HOWO
MIXER TRUCK :ISUZU ,NISSAN-UD ,HINO ,FUSO ,MITSUBISHI
PUMP TRUCK :PUTZMEISTER ,ZOOMLINE

TRADE TERMS ===========================Company age > 8 years ,Enjoy high reputation from consumer .Delivery time 7-15days after you place order Mainly market 1.Africa:Ghana ,Cameroon,Nigeria ,Kenya ,Mozambique ,Zimbabwe,Congo , Ethiopia ,Malawi,Sudan ,Senegal ,Zambia,Mali,
2.Asia: Iran ,Oman ,Pakistan ,Qazaqstan ,Myanmar, Cambodia ,Vietnam ,philippines ,Laos,
3.Austrilia .USA  ,Chile ,Paraguay, New Zealand ,Peru ,Shipped port shanghai sea port ,China Payment 30%deposit of T/T ,the balance should be clean before loading
The 70%deposit of T/T,the 30% should be paid against the Copy of B/L .Trade term FOB/CIF/CFR
EXPORT CASES/CLIENT VISIT  ================
