• Model NO.：ZCC2600
• F-Jib Length：12-30m
• Max.Lifting Capacity on Fixed Jib：34t
• F-Jib Angle：10,30
• Max. Lifting Capacity on Luffing Jib：73.5t
• Transport Package：Nude
• Specification：12180*3345*3205 mm
• Trademark：Zoomlion
• Origin：China
• HS Code：8426491000
• Production Capacity：1000pes,Year

ItemUnitValueRemarksMaximum lifting capacity × radiust × m260 × 5 Deadweight of crane with basic boomt210 Length of main boomS-boom lengthm20-83 SL-boom lengthm86-95 F-jib lengthm12-30 Max.lifting capacity on fixed jibt34 F-jib angle.10,30 Max. length of heavy duty boom with fixed jibm77+30 W-jib Length m21-60 Max. lifting capacity on luffing jibt73.5 S-boom angle( for SW boom configuration).65-85 Max. length of heavy duty boom with luffing jibm62+60 Single rope speed of winchesHoisting winch 1m/min130on the 6^th rope layerHosting winch 2m/min120on the 6^th rope layerMain boom derricking winchm/min80× 2on the 6^th rope layerSlewing speedrpm0-1.2 Traveling speedkm/h0-1.0 Max.gradeability%30 Ground pressureMPa0.115 Transport weight of max.single unitt32Excluding  hoisting winches,titling-back support of main boom.A-frame and derricking mechanismRear counterweightt83.7 Central counteweightt32 EngineManufacturer US Rated power/rotational speedKw/rpm227/2000 Max. output torque/rotational speedNm/rpm1505/1400 Emission standard U.S.EPA Tier 3 and EU Stage III A Pictures
