• Model NO.：ZCC2600
• Main Boom Length：20-83m
• Fixed Jib Length：12~30m
• Max. Lifting Capacity of Fixed Jib：34 T
• Slewing Speed：0-1.2r,Min
• Traveling Speed：0-1.0 Km,H
• Gradeability：30%
• Engine：Us Cumins
• Rated Power：227,2000kw,Rpm
• Transport Package：Nude Package
• Specification：10.6*7.1*3.65 m
• Trademark：Zoomlion
• Origin：China
• HS Code：84264910
• Production Capacity：10000

IteUnitValueMaximum lifting capacity × radiust × m260 × 5Deadweight of crane with basic boomt210Length of main boomS-boom lengthm20-83SL-boom lengthm86-95F-jib lengthm12~30Max.lifting capacity on fixed jibt34F-jib angle.10,30Max. length of heavy duty boom with fixed jibm77+30W-jib Length m21-60Max. lifting capacity on luffing jibt73.5S-boom angle( for SW boom configuration).65-85Max. length of heavy duty boom with luffing jibm62+60Single rope speed of winchesHoisting winch 1m/min130Hosting winch 2m/min120Main boom derricking winchm/min80× 2Slewing speedrpm0-1.2Traveling speedkm/h0-1.0Max.gradeability%30Ground pressureMPa0.115Transport weight of max.single unitt32Rear counterweightt83.7Central counteweightt32EngineManufacturer US CuminsRated power/rotational speedKw/rpm227/2000Max. output torque/rotational speedNm/rpm1505/1400Emission standard U.S.EPA Tier 3 and EU Stage III AContact me:
