• Model NO.：ZCC1300
• Main Boom Length：13 - 52
• Traveling Speed：0-1.6
• Max. Gradeability：30
• Engine Model：Wp6g190e26
• Rated Power / Rotational Speed：140,1900
• Exhaust Emission：National Stage II
• Package：Nude Package
• Type：Top-Slewing Crane
• Shipping Time：Within 15 Days Delivery
• Key Words：Truck Crane
• Usage：Lifting Goods
• Hydraulic Parts：Famous Brand Hydraulic Parts
• Application：Construction
• Color：Customer Requirements
• Transport Package：9.55*6.5*3.2 M
• Specification：9.55*6.5*3.2 m
• Trademark：ZOOMLION
• Origin：Hunan, China
• HS Code：84295212
• Production Capacity：500pices,Year

ItemUnitValueMaximum lifting capacity × radiust × m130 × 4.5Maximum lifting momentt × m661.5Deadweight of crane with basic boomt113.8Length of main boomm19-73Length of fixed jibm13-31Maximum lifting capacity with fixed jibt13Fixed jib angle.10,30Maximum length of main boom + fixed jibm55+31,58+25,61+19Single rope speed of winchesMain winch(hoisting winch 1)m/min105Auxiliary Winch(hosting winch 2)) m/min93derricking winchm/min52Slewing speedr/min0-2.2Traveling speedkm/h0~1.3Gradeability%30Ground pressureMPa0.1Overall dimensions(L × W × H)m9.55×6.5×3.2EngineRated power/rotational speedKw/rpm209/2000Max. output torque/rotational speedNm/rpm1424/1400Exhaust emission standard U.S.EPA Tier 3Distance between track center × crawler contact length × crawler shoe widthmm5600×6850×900
