• Model NO.：QY25K-ll
• Hydraulic Cylinder Brand：XCMG
• Rated Loading Capacity：25 Ton
• Feature：Truck Crane
• Rated Lifting Moment：1010kn.M
• Unique Selling Point：Long Lifetime
• Hydraulic Valve Brand：XCMG
• Max. Lifting Height：34.19m
• Hydraulic Pump Brand：XCMG
• Engine Brand：Shangchai
• Span：5.14m
• Max. Travel Speed：75km,H
• Max. Grade Ability：0.3
• Transport Package：Comply with Export Packaging Requirements
• Specification：12650*2500*3380,3290mm
• Trademark：XCMG
• Origin：Jiangsu, China
• Production Capacity：10000 Unit,Units Per Month

Overview Product Description



Detailed Photos



Product Parameters



DescriptionUnitParameter valueOverall lengthmm12650Overall widthmm2500Overall Heightmm3380Wheel Basemm4425+1350Trackmm2074/1834/1834Total vehicle mass in travel configurationkg29400Axle loadFront axlekg6600Rear axle22800Engine Model SC8DK280Q3Engine rated powerkw/(r/min)206/2200Engine rated torqueN.m/(r/min)1112/1400Max. travel speedkm/h75Min. travel speedkm/h2.9Min. turning diameterm22Min. ground clearancemm260Max. grade ability%30Approach angle°16Departure angle°13Braking distance (at 30 km/h, full load )m≤10Oil consumption per 100kmL≤37Exterior noise level during acceleration travelingdB (A)84Noise level at seated positiondB (A)90Company Profile
