• Model NO.：ZTC201V551
• Shaft Number：5
• Crane Jib：Four-Arm
• Type：Straight Arm
• Weight：20ton
• Max. Lifting Height：47.8m
• Option：Color, Hook Weight
• Certificate：ISO9001
• Max. Rated Total Lifting Capacity Kg：20000
• Transport Package：Nude Package
• Specification：12600*2500*3450
• Trademark：ZOOMLION
• Origin：China
• HS Code：8705109100
• Production Capacity：10000pieces,Year

Item

Value

Remarks

Working performance specification

Max. rated total lifting capacity kg

20000

Max. load moment of basic boomkN.m

850

Max. load moment with max. main boom lengthkN.m

458.6

Max. lifting height of main boom m

32.60

Deformation of boom is not taken into consideration.

Max. lifting height of fly jibm

40.4

Working speed

Max. speed of single rope on main winchm/min

120

The 4th layer of drum

Derricking time of booms

60

Telescopic time of booms

70

Slewing speedr/min

0~1.8

Traveling specification

Max. traveling speedkm/h

70

Min. turning circle diameterm

20

Min. ground clearancemm

250

Oil consumption per hundred kilometersL

40

Mass specification

Deadweight of crane in traveling conditionkg

26080

Complete vehicle kerb masskg

25885

Front axle loadkg

6380

Rear axle loadkg

19700

Dimension specification

Overall dimensions (L×W×H) mm

12320*2500*3400

Base on outriggersm

4.95

Distance between outriggersm

5.6

Fly jib lengthm

8

Company Profile

Our Advantages

OUR SERVICE
1)Professional fast response mechanical engineers and electrical engineers provide suitable solution method for you all around the world.
2)Engineers available to reach machinery overseas job site at any time required.
3) Technical Support of installation/training supplied to help customers to earn most profits with our machinery.
4) All variety of spare parts available to support the customer 24h*7days for the daily maintenance/repair purpose etc.
OUR PRICE
We work as the leading VIP dealers of various famous Chinese construction machinery manufacturers and are constantly treated with best price policy which is only provided to special internal high level permission.From numerous comparison and feedback from clients.Our price is always more competitive and much favorable than the customer buy directly from manufacturers.



1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted

2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,

3: What about the delivery time?
A: 7-20 days after receiving the deposit.

4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.

5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs
