16 Ton Single Girder Overhead Crane with Double Speed Hoist
HENAN NYBON MACHINERY CO., LTD.- After-sales Service：Online Instruction,Engineers Available to Service
- Warranty：2 Year
- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Operation Form：Air Operation+Ground Operation
- Maximum Lifting Height：25-30m
Base Info
- Maximum Lifting Weight：<20t
- Main Girder Form：Single Girder
- Type：Ordinary
- Product Name：10 Ton Single Girder Overhead Bridge Crane
- Power Supply：3pH AC
- Lifting Speed：7-8m,Min
- Cross Travelling Speed：20m,Min
- Crane Travelling Speed：20m,Min
- Working Class：A3-A5
- Lifting Mechanism：Wire Rope Hoist
- Similar Model：Ldp,Ldc,Lb,Lz
- Recommended Rail Width：37~70mm
- Lifting Height：6,9,12,18,24,30m
- Color：Yellow or Customized
- Transport Package：Standard Export Package
- Specification：16 ton
- Trademark：NYBON
- Origin：Henan
- HS Code：84261120
- Production Capacity：120set,Month
Description
Overview
Product Description
Main Technical Parameter
Capacity
t
1,2,3,5,10
16,20
Span
m
7.5-22.5
Lifting height
m
6,9,12,18,24,30
12,18,24,30
Speed
Lifting
m/min
8,8/0.8,7/07
3.5,3.5/0.35
Cross travel
m/min
20,30
20,30
Long travel
m/min
20,30,45,60,75
Electric hoist
type
CD/MD
CD/MD/HC
Working duty
A3
A3
Power supply
AC
380V/50HZ/3P
380V/50HZ/3P
