• Main Girder Form：Double Girder
• Product Name：High Quality 40 Ton Rubber Tyre Port Gantry Crane
• Application：Lifting
• Voltage：Customized
• Span：Customized
• Lifting Height：According to Your Requirement
• Transport Package：Wood Carton, Waterproof Plastic Clothes
• Specification：16*8.0*10m
• Trademark：NYBON
• Origin：Henan, China
• HS Code：8426194200
• Production Capacity：1000 Sets,Year

Capacity(under spreader) (t)30.53540.550Working dutyA6A6A6A6Span(m)35353535Cantilever length(m)12121212Base(m)16161616Lifting height(m)15.415.418.218.2SpeedHoisting speed(m/min)1218181824363636trolley travel mechanism(m/min)60607070crane travel mechanism(m/min)45454545Total power (kw)~200~230~255~300Max. working load of wheel (KN)260265280300Power supplyAC, 3Phase, 380V, 50Hz








Packing & Delivery terms:
1. Hoist and electric parts will be packed by plywood crate, for avoiding the demage from goods crash and impact
during the delivery.

2. Girders and other main parts will be packed by plastic woven cloth, for preventing rust from soppy condition during
the transportation.

3. Only the best transport solution will be taken for saving your cost uttermost on finance, security and time.









  A. How can I get a precise crane offer?Please confirm the specifications below:

1. Lifting capacity; how many ton?
2. Lifting height: how many m?
3. Crane span(the width of inquired crane): How many m?
4. Crane traveling length; when rail track/runway beam needed, traveling length shall be provided.
5. Working power; power source at site(unit as voltage, phase and Hz)
6. Working class: how many hours shoud the crane work/day

B.What operation methods can we choose?

1. Pendent control ;
2. Remote control ;
3. Cabin controtl

C.How to install the crane at our site?
NYBON engineer team will offer you installatiaon guide and training,we can also send our team to your country for installation.
