Double Girder Gantry Crane 40 Ton with Both Overhang

HENAN NYBON MACHINERY CO., LTD.
  • Certification：CE, ISO9001
  • Condition：New
  • Maximum Lifting Weight：20-50t
  • Maximum Lifting Height：25-30m
  • Operation Form：Cabin
  • Type：Common Gantry Crane

Base Info

  • Model NO.：MG
  • Main Girder Form：Double Girder
  • Overhang：5~12 M
  • Transport Package：Special Waterproof Plastic Close for Expor, 40ot
  • Specification：40 Ton
  • Trademark：NYBON
  • Origin：Henan, China
  • HS Code：8426193000
  • Production Capacity：100 Sets,Year

Description

Rated load/ton40  75 100 150 200Span/m10-40     Lifting height/m30     Working classA5/2M     Lifting speed/m/min 5.96.0  4.4 3.22.4 Trolley running speed/m/min 38.4 38.4 33.8 30 25Crane running speed/m/min 30 3030 30  30Dead weight/t112~185 148~220172~265  215~300 245~380 Number of wheel  8 16 16 24 24Max. wheel pressure/KN 288~375 210~255 255~310 230~285 295~355Steel track recommended QU70 QU100 QU100 QU100 QU100 Power supply

3AC  220~480V  50/60Hz
