• Model NO.：LDA
• Maximum Lifting Weight：<20t
• Main Girder Form：Single Girder
• Type：Single Girder Crane
• Weight Overload Protection Device：Include
• Voltage Lower Protection Function：Include
• GB/T 24001-2004 Idt ISO14001: 2004：Pass
• Sandblast：Could Supply
• GB/T 19001-2000 Idt ISO 9001: 2000：Pass
• Limited Switch：Include
• Painting Color：According to Your Demand
• Current Overload Protection System：Include
• GB/T 28001-2001, OHSAS18001: 1999：Pass
• Electric Hoist Double Limit：Include
• Application：Workshop Usage, Mineral Area Usage
• Sling Type：Wire Rope
• Power Source：Electric
• Moving Type：Wheel
• Installation：Overall Rapid Disassembly
• Transport Package：Packed by Plywood Crate and Plastic Woven Cloth.
• Specification：China National standard
• Trademark：KUANGYUAN
• Origin：Xinxiang, Henan Province
• HS Code：84261120
• Production Capacity：29, 000 Sets,Year

Lifting CapacityT 1t2t3t5t10t 16t20t Spanm 7.5~22.5m7.5~31.5 SpeedLiftingMD1 hoistm/min8/0.8 (7/0.7) 3.5/0.35CD1 hoist8 (7)  3.5Traveling of electric hoist 20  20Traveling of crane20/30 20/30Wheel diameterΦ270Φ370Width of trail37~70mm37~70mmOperational Modelremote control; ground handleremote control; ground handleWorking DutyA3A3Power SupplyThree-phase A.C. 380V, 50HzThree-phase A.C. 380V, 50Hz
