5~74 Ton Qdy Model Ladle Foundry Casting Crane
Henan Kuangshan Crane Co., Ltd.- Certification：GS, CE, ISO9001
- Condition：New
- Operation Form：Air Operation+Ground Operation
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：>200t
- Main Girder Form：Double Girder
Base Info
- Model NO.：QDY
- Type：Bridge Crane
- Working Class：A7, A8
- Main Electric Parts：Siemens,Schneider
- ISO 9001: 2008：Passed
- Limit Switch：Included
- Power Source：Electric
- Moving Type：Wheel
- Installation：Assembled
- Transport Package：Plastic Woven Cloth,Polywood Case
- Specification：GB,T3695-2008
- Trademark：Kuangyuan
- Origin：Henan, China
- HS Code：84261120
- Production Capacity：8000sets Per Year
Description
Capacity
t
5
10
16/3.2
20/5
32/5
50/10
74/20
Span
m
10.5~31.5
13.5~31.5
Max. Lifting Height
Main hook
m
16
16
16
12
16
12
22
Auxiliary hook
18
14
18
16
24
Speed
Main hoisting
m/min
15.5
10.4
10.7
9.8
7.8
7.8
6.1
Auxiliary hook
14.6
15.5
15.5
10.4
9.7
Trolley travelling
37.2
43.8
44.6
44.6
42.4
39.3
33.8
Crane travelling
92.7
93.7
92.7
93.7
86.5
76
89
76
89
89
75.3
75.3
75
76.6
67.3
Motor
Main hoisting
Kw
15
22
37
45
55
75
90
Auxiliary hoisting
11
15
15
22
37
Trolley travelling
1.5
2.2
3.7
3.7
7.5
11
15
Crane travelling
2 × 5.5
2 × 7.5
2 × 5.5
2 × 7.5
2 × 7.5
2 × 11
2 × 7.5
2 × 11
2 × 11
2 × 11
2 × 15
2 × 22
Power supply
3-phrase 50HZ 380V
