• Model NO.：KB5.0
• Type：Straight Arm
• Max. Lifting Load：5ton
• Lifting Height：16.8m
• Underground Lifting Height：20.5m
• Weight：6000kg
• Transport Package：Nude
• Specification：CE, ISO
• Trademark：KEBU
• Origin：Henan, China
• HS Code：842649100
• Production Capacity：50 Sets,Month

Model
KB5.0
Specifications
5.0t×2.5m
Maximum working radius
16m ×0.21t
Maximum lifting height
16.8m
Winding
Hook up speed
8-16m/min(4)
Hoist rope type
¢8mm×100m
Telescopic systen
Boom type
Full automatic 5 section
Boom length
16.475m
Up and downs
Hoist angle/speed
0°-80°/24.5 sec
Rotary
Rotation angle
360° continuous/2.1rpm
Outrigger
Type
Manual adjustment for the 1 section,and automatic for the 2,3 section.
Maximun extended  dimensions
5431mm ×5298mm
Traction system
Drive
Hydraulic motor driven,stepless speed changer
Travel speed
0-3.3 km/h
Track
Synthetic rubber
grade ability
20°
Ground pressure
49.0kpa
