Item | Value | Remarks |
Work performance | Max. rated lifting capacitykg | 150000 | At 3 m radius |
Max. load moment of basic boom kN.m | 4704 | At 6 m radius |
Max. load moment of main boom (fully extended)kN.m | 1505 | At 32 m radius |
Max. lifting height of basic boom m | 13 | |
Max. lifting height of main boomm | 72.5 | The parameters do not include deflection of main boom and jib. The value in the brackets is the value with the extension installed. |
Max. lifting height of jibm | 87/ (95) |
Work speeds | Max. hoist rope speed (Main winch) m/min. | 114 | At the 4th layer |
Max. hoist rope speed (Auxiliary winch) m/min. | 75 | At the 3rd layer |
Boom derricking up times | 94 | |
Boom extending time s | 860 | |
Max. slewing speedr/min. | 1.4 | |
Driving | Max. height above sea level m | 2000 | |
Max. driving speed km/h | 78 | |
Max. gradeability% | 40 | |
Min. turning diameter m | ≤23 | |
Min. ground clearancemm | 320 | |
Limits for exhaust pollutants and smoke | Conform to related standards | GB3847-2005 |
GB17691-2005 (National Stage ) |
Fuel consumption per hundred kilometersL | 70 | |
Mass | Deadweight in driving condition kg | 54900 | |
Complete vehicle kerb mass kg | 54705 | |
Load on axles 1 and 2 kg | 9950+9950 | |
Load on axles 4 and 5 kg | 12625+12625+9750 | |
Dimensions | Overall dimensions (L × W × H) mm | 15400×3000×3940 | |
Outrigger spread (L) m | 8.05 | |
Outrigger spread (W)m | 7.8 (fully extended), 5.3 (intermediately extended) | |
Main boom length m | 13.5~72.0 | |
Boom angle ° | -0.5~82 | |
Jib lengthm | 11 ,18.6 | |
Jib + extension length m | 26.6 | |
Offset° | 0 ,30 | |
