Cheap Lifting Machine 25 Ton Mobile Crane Stc250 Price
Newindu Construction Engineering (Shanghai) Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Maximum Lifting Height：30-40m
- Maximum Lifting Weight：>16t
- Shaft Number：3
- Crane Jib：Four-Arm
Base Info
- Model NO.：STC250
- Type：Straight Arm
- Max.Lifting Capacity：25t
- Engine Model：80km,H
- Engine Rated Power：213,2100kw
- Fully Extended Boom+ Jib：41.5m
- Transport Package：Container Roro Bulk Break Shipment
- Specification：30t
- Trademark：Newindu
- Origin：Hunan
- HS Code：8705109100
- Production Capacity：50PCS,Month
Description
Basic Info.
Model NO. STC250 Type Straight Arm Max.Lifting Capacity 25t Engine Model 80km/H Engine Rated Power 213/2100kw Fully Extended Boom+ Jib 41.5m Transport Package Container Roro Bulk Break Shipment Specification 30t Trademark Newindu Origin Hunan HS Code 8705109100 Production Capacity 50PCS/MonthProduct Description
Cheap lifting 25 Ton Truck mobile Crane machinery STC250 price
Feature
Powerful Lifting Capacity
STC250 25 ton crane has four-section boom of high strength steel structure and optimized U-shaped cross section with max.lifting capacity of 25t, full-extended boom length of 33.5m, max.lifting height including jib of 42m, reduce weight and improve safety significantly.
Jib mounting angles are 0°, 15°, and 30°, which ensure fast and convenient change-over between different operating conditions so as to improve working efficiency of the machine.
Efficient & Unique Hydraulic System
Triple gear pump, load feedback and constant power control are applied to provide strong lifting capacity and good micro-mobility. Unique steering buffer design guarantees smooth braking operation.
Intelligent Electronic Control
Self-developed controller SYMC special for engineering machinery is configured. The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness, and high reliability. Timely feedback of data information can achieve the monitoring of the overall working status in real time.
The Load Moment Limiter
Equipped with the comprehensive intelligent protection system is used with accuracy within 3%. The adoption of comprehensive logic and interlock control system ensures more safe and reliable operation.
Parameters
| Dimension | Unit | STC250 |
|---|---|---|
| Overall length | mm | 12750 |
| Overall width | mm | 2500 |
| Overall height | mm | 3550 |
| Weight | ||
| Total weight in travel | kg | 30000 |
| Front axle load | kg | 6500 |
| Rear axle load | kg | 23500 |
| Power | ||
| Engine model | Cummins | |
| Engine rated power | kW/(r/min) | 213/2100 |
| Engine rated torque | N.m/(r/min) | 1050/1200~1400 |
| Travel | ||
| Max. travel speed | km/h | 80 |
| Min. turning diameter | m | 10 |
| Min. ground clearance | mm | 220 |
| Approach angle | ° | 17 |
| Departure angle | ° | 12 |
| Max. grade ability | % | 38 |
| Fuel consumption for 100km | L | 37 |
| Main performance | ||
| Max. rated total lifting capacity | t | 25 |
| Min. rated working radius | m | 3 |
| Turning radius at turntable tail | m | 3.37 |
| Max. lifting torque | kN.m | 962 |
| Base boom | m | 10.65 |
| Fully extended boom | m | 33.5 |
| Fully extended boom+ jib | m | 41.5 |
| Longitudinal outrigger span | m | 5.3 |
| Lateral outrigger span | m | 6.2 |
| Working speed | ||
| Boom luffing time | s | 70/50 |
| Boom full extension time | s | 70/55 |
| Max. swing speed | r/min | 0~2.0 |
| Max. speed of main winch (single rope) (no load) | m/min | ≥120 |
| Max. speed of aux. winch (single rope) (no load) | m/min | ≥120 |
