| Item | Unit | Value | Remarks |
|---|
| Working performance | Max. rated lifting capacity | kg | 55000 | |
| Max. load moment of basic boom | kN.m | 2009 | |
| Max. load moment of main boom(fully extended) | kN.m | 1050 | |
| Max. load moment of basic boom | m | 12.6 | |
| Max. lifting height of main boom | m | 43.6 | These parameters do not include deflection of main boom and jib |
| Max. lifting height of jib | m | 58 |
| Working speeds | Max. hoist rope speed(Main winch) | m/min | 120 | |
| Max. hoist rope speed(Auxiliary winch) | m/min | 120 | |
| Boom demrricking up time | s | 50 | |
| Boom demrricking up time | s | 95 | |
| Slewing speed | r/min | 0-2.2 | |
| Driving parameters | Max. height above sea level | m | 2000 | |
| Max. driving speed | km/h | 76 | |
| Max. gradeability | % | 40 | |
| Min. turning diameter | m | ≤24 | |
| Min. ground clearance | mm | 260 | |
| Oil consumption per hundred kilometers | L | 43 | |
| Mass | Deadweight in driving condition | kg | 42000 | |
| Complete vehicle kerb mass | kg | 41870 | |
| Front axle load | kg | 16000 | |
| Rear axle load | kg | 26000 | |
| Dimensions | Overall dimensions(L×W×H) | mm | 13700×2800×3800 | |
| Outrigger spread(L) | m | 5.92 | |
| Outrigger spread(W) | m | Fully extended:7.1,intermediately extended:4.8 | |
| Tail slewing radius | mm | 3900 | |
| Main boom length | m | 11.4 - 43.0 | |
| Boom angle | ° | -2 - 80 | |
| jib length | m | 9.2,14.6 | Low-mounted, open-type |
| Offset | ° | 5,25,45 | |
