• Model NO.：QY55V532.2
• Type：Straight Arm
• Max. Rated Lifting Capacity：55000kg
• Max. Load Moment of Basic Boom：2009 Kn.M
• Max. Lifting Height of Jib：59.5m
• Boom Demrricking up Time：50 S
• Slewing Speed：0-2.2 R,Min
• Max. Driving Speed：76 Km,H
• Turning Diameter：<24m
• Min. Ground Clearance：260 mm
• Tail Slewing Radius：3900 mm
• Main Boom Length：11.4 - 43.0 M
• Jib Length：9.5,16.0 M
• Max. Gradeability：40%
• Front Axle Load：16000kg
• Rear Axle Load：26000 Kg
• Max. Lifting Height of Main Boom：43.6 M
• Transport Package：Nude Package
• Specification：13700x2800x3650mm
• Trademark：Zoomlion
• Origin：China
• HS Code：8705109200
• Production Capacity：50000PCS,Year

ItemUnitValueWorking    performanceMax.    rated lifting capacitykg55000Max.    load moment of basic boomkN.m2009Max.    load moment of main boom(fully extended)kN.m1050Max.    load moment of basic boomm12.6Max.    lifting height of main boomm43.6Max.    lifting height of jibm59.5Working    speeds              Max.    hoist rope speed(Main winch)m/min120Max.    hoist rope speed(Auxiliary winch)m/min120Boom    demrricking up times50Boom    demrricking up times95Slewing  speedr/min0-2.2DrivingMax.    driving  speedkm/h76Max.    gradeability%40Turning    diameterm≤24Min.  ground clearancemm260Oil    consumption per hundred kilometersL43MassDeadweight    in driving conditionkg42000Complete    vehicle kerb masskg41870Front    axle loadkg16000Rear    axle loadkg26000DimensionOverall    dimensions(L×W×H)mm13700×2800×3650Longitudinal    distance between outriggersm5.92Transversal    distance between outriggersmFully    extended:7.1,
     Intermediately    extended:4.8Tail    slewing radiusmm3900Main    boom lengthm11.4    - 43.0Main    boom angle°-2    - 80jib    lengthm9.5,16.0Offset°0,30
