• Model NO.：hydraulic truck crane
• Shaft Number：3
• Crane Jib：Five-Arm
• Type：Folding
• Overall Dimension：14770X2800X3890mm
• Wheel Base：2380+2075mm
• Track：2074,1834,1834mm
• Max. Travel Speed：80km,H
• Min. Travel Speed：3km,H
• Min. Turning Diameter：24m
• Min. Ground Clearance：371mm
• Max. Grade Ability：40%
• Application：Construction Lifting
• Engine Rated Power：290,1900kw,(R,Min)
• Engine Rated Torque：1900,1000-1400n.M,(R,Min)
• Approach Angle：17degree
• Departure Angle：15.5degree
• Braking Distance：Less Than10m
• Max. Total Rated Lifting Capacity：80t
• Transport Package：Nacked
• Specification：CE
• Trademark：Super-above
• Origin：Jiangsu, China
• HS Code：8705109100
• Production Capacity：10000PCS,Year

DescriptionUnitParameter valueOverall lengthmm14770Overall widthmm2800Overall Heightmm3890Axle base1st ,2nd axlemm14702nd ,3rd axle40003rd ,4th axle1350Wheel Basemm 2380+2075Total vehicle mass in travel configurationkg50000Axle load   1st and 2nd Axlekg240003rd and 4th Axle26000Engine Model WP12.375NMC11.39-30Engine rated powerkw/(r/min)276/1900290/1900Engine rated torqueN.m/(r/min)1800/1000-14001900/1000-1400Max. travel speedkm/h80Min. steady travel speedkm/h3Min. turning diameterm24Min. turning diameter at boom tipm29Min. ground clearancemm371Max. grade ability%40Approach angle°17Departure angle°15.5Braking distance (at 30 km/h, full load )m≤10Oil consumption per 100kmL45
