HBQZ Straight Arm Dongfeng 4*2 Chassis 3.2ton Mobile Truck Crane for Pick Up (SQ3.2S3)

Hubei Jiaheng Technology Co., Ltd.
  • After-sales Service：1 year
  • Warranty：1 year
  • Certification：ISO9001
  • Condition：New
  • Maximum Lifting Height：10-15m
  • Maximum Lifting Weight：2-4t

Base Info

  • Model NO.：SQ3.2S3
  • Shaft Number：2
  • Crane Jib：Three-Arm
  • Type：Straight Arm
  • Material：HG70
  • Max Lifting moment：80Kn.m
  • Max Lifting Capacity：3.2T
  • Max Lifting Height：10m
  • Working Radius：7.4m
  • Boom Section：3 stages
  • Rotation Angle：360°All Rotaion
  • Working Pressure：16MPa
  • Rated Oil Flow：30 L,min
  • Oil tank Capacity：100L
  • Winch type：Hydraulic
  • Swing type：Planetary gear reduction
  • Outrigger：adjustable, Hydraulic operating.
  • Outrigger Span：1750-3550mm
  • Installation Space：800mm
  • Transport Package：Nude or Customized
  • Specification：1500kg crane weight
  • Trademark：HBQZ
  • Origin：China
  • HS Code：8426910000
  • Production Capacity：80 Unit,Units Per Month

Description

Max Lifting Capacity (kg/m)3200/2.51100/4800/5.3400/7.4Max Lifting Height10mWorking Radius7.4mBoom Section3 stagesRotation Angle360°All RotaionWorking Pressure16mpaRated Oil Flow30 L/minOiltank Capacity100LWinchtypeHydraulicSwingtypePlanetary gear reduction.Outriggeradjustable, Hydraulic operating.Outrigger Span1750-3550mmCrane Weight1500 kgInstallation Space800mmSafety DeviceLoad Indicator, Hydraulic Safety Valve, Counter Balance Valve, Automatic Swing Brake, Hook Safety Device.MaterialHG70 10.00R20 tubeless tire, 7 pieces including one spare tire

HBQZ Straight Arm Dongfeng 4*2 Chassis 3.2ton Mobile Truck Crane for Pick Up (SQ3.2S3)
HBQZ Straight Arm Dongfeng 4*2 Chassis 3.2ton Mobile Truck Crane for Pick Up (SQ3.2S3)
HBQZ Straight Arm Dongfeng 4*2 Chassis 3.2ton Mobile Truck Crane for Pick Up (SQ3.2S3)
HBQZ Straight Arm Dongfeng 4*2 Chassis 3.2ton Mobile Truck Crane for Pick Up (SQ3.2S3)HBQZ Straight Arm Dongfeng 4*2 Chassis 3.2ton Mobile Truck Crane for Pick Up (SQ3.2S3)
