• Model NO.：zz1257M3641
• Type：Tower Crane
• Crane Max Lifting Capacity：12 Ton
• Working Radius：2.5~9.78 M
• Color：White or as Customers′ Option
• Driving Type：LHD,Rhd
• Cargo Material：Carbon Steel
• Engine Power：267HP
• Installation Space：1400 mm
• Main Girder Form：Single Girder
• Power Source：Hydraulic
• Transport Package：Nude
• Specification：ISO
• Trademark：Sinotruk HOWO
• Origin：China
• HS Code：8704
• Production Capacity：800 Units,Month

SPECIFICATIONParameters nameUnitParameters sizeChassis model/ZZ5311M4261C1Vehicle sizemm11998*2498*3880Total masskg31000Curb weightkg17700Rated Loadkg13170Van sizemm800*2300*550Steel spring Nopcs11/11/12Front/Rear overhang mm1320/2828Front/Rear wheel treadmm1986/1830Appoach/Deaparture angle°20.5/17Numbers of Alxepcs4Axle loadkg6500/7000/17500Max speedkm/h80Wheelbasemm2300+4200+1350Numbers of tirepcs12 piece+1 spare tireTire/11.00.00-20 18PREmmission standard/Euro IICabin/2-3 passengerEngine Model/615.92EEngine type/Diesel 4-stroke direct injection ,  6-cylinder in-line with water cooling, turbo-charging and inter-coolingDisplacementml9726Engine powerhp267CraneType/XCMG SQ12SK3QCrane Weightkg4200Max lifting capacitykg12000Max lifting momentT.M30Recommend powerkw30Max oil flow of hydraulic systemL/min63Rated pressure of hydraulic systemMpa26Oil tank capacityL180Installation spacemm1300Rotation angle°360
Our Advantage
1.Competitive Factory Price and Excellent Quality
2.More than 20 years' experience as a manufacturer
3.Products Quality Certification SGS CCC ISO
4.Perfect after-sale service
5.Customized products available with us
6.Export to more than 50 countries and regions
7.Oversea wareshouse with more than 100000 US dollors spare parts in stock
8.Oversea office with more than 15 professional engineers to help local customers

Main products
1. Dump Truck / Tipper Truck
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )

FAQ
1. MOQ: 1 unit
2. Optional payment terms: T/T or L/C
    T/T: 30% deposit by T/T, 70% balance should be paid before shippment.
    L/C: 30% payment advance, 70% L/C at sight.
3. Parts of famous brand can be adopted by your requirement, such as WABCO, JOST, BPW, FUWA.
4. Delivery time: Within15 workdays after receiving 30% deposit of T/T

Warranty
1. One year quality guarantee for three key parts axles, engine, transmission or within 100000km, which comes the first.
2. Other spare part could be supplied by OEM at cost prices.
3. Regularly callback to know the vehicle's working status.
4. The overseas engineers are always ready to deal with unexpected needs.

Your are always welcome to visit our factory at any time.
