Hydraulic 70ton Mobile Truck Crane with Good Price
Uptra Electric & Machinery (Shanghai) Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：70ton
- Shaft Number：3
- Crane Jib：Five-Arm
Base Info
- Model NO.：hydraulic truck crane
- Type：Folding
- Overall Dimension：13930X2800X3575mm
- Wheel Base：2304+2075mm
- Track：2074,1834,1834mm
- Max. Travel Speed：80km,H
- Min. Travel Speed：3km,H
- Min. Turning Diameter：24m
- Min. Ground Clearance：327mm
- Max. Grade Ability：40%
- Application：Construction Lifting
- Engine Rated Power：276,2200kw,(R,Min)
- Engine Rated Torque：1500,1400n.M,(R,Min)
- Approach Angle：19degree
- Departure Angle：11degree
- Braking Distance：Less Than10m
- Max. Total Rated Lifting Capacity：70t
- Transport Package：Nacked
- Specification：CE
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：8705109100
- Production Capacity：10000PCS,Year
Description
WD615.338Engine rated power kw/(r/min) 276/2200 Engine rated torque N.m/(r/min) 1500/1400 Engine rated rotational speed r/min 2100 Max. travel speed km/h 80 Min. steady travel speed km/h 3 Min. turning diameter m 24 Min. turning diameter at boom tip m 29 Min. ground clearance mm 327 Max. grade ability % 40 Approach angle ° 19 Departure angle ° 11 Braking distance (at 30 km/h, full load ) m ≤10 Oil consumption per 100km L 45 Max. total rated lifting capacity t 70 Min. rated working radius m 3 Turning radius at turntable tail mm 3550 Max. load moment Base boom KN.m 2303 Max. load moment Fully-extended boom KN.m 1129 Max. load moment Fully-extended boom + Jib KN.m 580.2 Hoist height Base boom m 11.8 Hoist height Fully-extended boom m 44.2 Hoist height Fully-extended boom + Jib m 59.4 Boom length Base boom m 11.6 Boom length Fully-extended boom m 44.5 Boom length Fully-extended boom + Jib m 59.5
