• Model NO.：DGY36
• Normal Dipper Capacity：0.5m
• Rated Power of Engineer：125kw
• Digging Force of Bucket：52.7kn
• Operating Model：Hydraulic Servo
• Overall Dimensions(Lxwxh)：10200mm *4350mm *8650mm
• Max. Lifting Height：11800mm
• Crawler Length：4256mm
• Crawler Width：3180mm
• Crawler Plate Thickness：800mm
• Transport Package：Nude
• Specification：CE, ISO9001: 2000
• Trademark：SINOHENG
• Origin：China
• Production Capacity：500PCS,Month

Basic Info.

Model NO. DGY36 Normal Dipper Capacity 0.5m Rated Power of Engineer 125kw Digging Force of Bucket 52.7kn Operating Model Hydraulic Servo Overall Dimensions(Lxwxh) 10200mm *4350mm *8650mm Max. Lifting Height 11800mm Crawler Length 4256mm Crawler Width 3180mm Crawler Plate Thickness 800mm Transport Package Nude Specification CE, ISO9001: 2000 Trademark SINOHENG Origin China Production Capacity 500PCS/Month

Product Description

Hydraulic Multifunctional Pipelayer Machine DGY36 with hydraulic system, lifting crane and excavator for pipes engineering constructions
Overal weight: 25MT
Normal dipper capacity: 0.5M
Rated power of engineer: 125KW
Rated rotation speed: 2100rpm
Pressure of hydraulic system: 34.3MPa
Rate of flow: 2*226L/Min.
Slewing speed: 11.7rpm
Max. Traction: 174KN
Max. Travelling speed (High/low): 5.2/3.5Km/h
Gradeability: 30°
Digging force of bucket: 52.7KN
Average landingspecific presssure: 61KPa
Operating mode: Hydraulic servo
Overall length: 10200mm
Overall width: 4350mm
Overall height (top of boom): 8650mm
Overall height (top of operator's cab): 2961mm
Bob-weight ground clearance: 1116mm
Min. Ground clearance: 480mm
Turning radius at swing table tail: 3090mm
Crawler landing length: 3445mm
Crawler length: 4256mm
Crawler gauge: 2380mm
Crawler width: 3180mm
Crawler plate thickness: 800mm
Turntable width: 2710mm
Max. Digging height: 11200mm
Max. Dump height: 9480mm
Max. Digging depth: 4440mm
Max. Vertical digging depth: 3650mm
Max. Digging radius: 10715mm
Max. Height at min. Turning radius: 8335mm
Autofit external diameter of swing pipe: 813mm
Max. Length of swing pipe: 12m
Max. Lifting load of loading boom: 12MT
Boom length: 11.7m
Bob-weight height: 2068mm
Landing length (transportation): 5162mm
Magnification of winch steel wire rope: 6
Diameter of winch steel wire rope: 10mm
Max. Lifting height: 11800mm
