New Hydraulic Mobile Crane 100 Ton Crawler Crane (Quy100)
Sinomada Heavy Industry (Changsha) Co., Ltd.- Max. Lifting Height：72m
- Rated Loading Capacity：100t
- Certification：ISO9001, CE, RoHS, BV
- Condition：New
- Warranty：1 Year
- Max Load Moment：5500kn.M
Base Info
- Model NO.：QUY100
- Max. Swing Speed：1.4r,Min
- Max. Travel Speed：1.1km,H
- Engine Power：200kw
- Transport Package：Roro,Container,Nude
- Specification：9600*3300*3300mm
- Origin：China
- HS Code：8426491000
- Production Capacity：50units,Month
Description
Overview
Product Parameters
Company Profile
Max. lifting capacity
Boom
t
100
Jib
t
11
Max. load moment
kN.m
5500
Boom length
m
18~72
Boom elevating angle
°
0~80°
Fixed jib length
m
12~24
Fixed jib offset
10°,30°
Max. single line hoist speed (at 5th layer with no load)
m/min
120
Max. single line elevating speed (at 5th layer with no load)
m/min
45
Max. swing speed
r/min
1.4
Travel speed
km/h
1.1
Min. elevating time
s
240
Winch hoist speed(with full load)
m/min
4
Max. grade-ability
30%
Mean ground pressure
MPa
0.0927
Engine output
kW
200
Total mass (main hook block,18m boom)
t
114
Max. base machine weight for transport
(without counterweight, L/R crawler, lattice boom)
t
40.0
Max. base machine dimension for transport (L×W×H)
m
9.6×3.3×3.3
