• Model NO.：QUY75
• Max. Swing Speed：2.4r,Min
• Max. Travel Speed：1.2km,H
• Engine Power：200kw
• Transport Package：Roro,Container,Nude
• Specification：12600*3320*3230mm
• Origin：China
• HS Code：8426491000
• Production Capacity：50units,Month

Max.rated lifting capacity

Basic boom

t

70

Fixed jib

t

6.5

Max. load moment

kN-m

2744

Main boom length

m

13-58

Main boom Luffing angle

°

30-80

Fixed jib length

m

9-18

Winch max. single line speed( no load,at 5th layer)

m/min

120

Boom luffing gear max. single line speed( at 1th layer)

m/min

57

Max. swing speed

r/min

2.4

Max. travel speed

km/h

1.2

Max. grade-ability

%

30

Mean ground pressure

MPa

0.087

Engine output power

kW

200

Gross vehicle mass (including main hook block and 13m boom)

t

61

Max. weight of single unit in travel configuration

t

39

Max. dimension of single unit in travel configuration (L×W×H)

m

12.6×3.32×3.23
