• Model NO.：RT60
• Type：Straight Arm
• Wheelbase：3950mm
• Transport Package：Roro,Bulk,Nude,Container
• Specification：13662*3300*3750
• Trademark：ZOOMLION
• Origin：China
• HS Code：87051091
• Production Capacity：100units,Month

Overview Product Description

Product Parameters



Work performanceMax. rated lift capacity × work radiuskg.m60000×2.8Max. load moment of basic jibkN.m1991Max. load moment of max. length main boomkN.m1166Max. lifting height of max. length main boom    m45.4Max. lifting height of jibm62.2DimensionsOverall dimensions(L×W×H)mm13662×3300×3750Distance between outriggers (Longitudinal × transversal)mm6900×6900Main boom length (Completely retracted - completely extended)mm11400 - 43000Jib length (Jib section 1,jib sections 1+2)mm10000-17000Boom angle°-3 - 78Swing range°360°unlimited swing(Full range)Work SpeedsMax. hoist rope speed (Main winch)m/min150Min. boom telescoping out times140Min. boom telescoping in times120Min. boom derrick up times60Min. boom derrick down times65Swing speedr/min0-2Hydraulic systemRated working pressureMPa28Rated working flowL/min400Hydraulic oil tank capacityL730MassComplete vehicle kerb masskg44260Front axle loadkg25220Rear axle loadkg19040DrivingMax. driving speed (Forwarsd / backwards)km/h39Wheelbasemm3950Treads (Front / rear)mm2605Max. gradeability%75 Detailed Photos
