Item | Unit | Value | Remarks |
---|
Max. lifting capacity / radius | US Tons/ft(mt/m) | 110/10'6"(100/3.2) | |
Max. lifting capacity of fixed jib | US Tons (mt) | 8.8(8) | |
Main boom length | ft(m) | 42'8"-219'10"(13-67) | |
Fixed jib length | ft(m) | 180'5"+59'(55+18) | |
Main boom angle | . | 30-82.5 | |
Fixed jib angle | . | 10,30 | |
Rope speed of hoisting winches 1 and 2 | With free-fall function | ft/min(m/min) | 325(99) | On the 4th rope layer |
Without free-fall function | ft/min(m/min) | 393(120) | On the 4th rope layer |
Single rope speed of derricking winch | ft/min(m/min) | 190(58) | On the 4th rope layer |
Max./rated single rope force of hoisting winches 1 and 2 | With free-fall function | Lbs(mt) | 44100/29988(20/13.6) | With optional free-fall function |
Without free-fall function | Lbs(mt) | 31311/27342(14.2/12.4) | On the 1st rope layer |
On the 1st rope layer |
Max.single rope force of derricking winch | Lbs(mt) | 15656(7.1) | On the 1st rope layer |
Slewing speed | r/min | 0-2.3 | |
Traveling speed(high/low speed) | mph(km/h) | 0.78/0.31(1.25/0.5) | |
Gradeability | %(°) | 30%(16.7° | |
Max.transport weight of basic machine | Lbs(mt) | 99887(45.3) | |
Deadweight(with basic boom) | Lbs(mt) | 189630(86) | |
Counterweight | Lbs(mt) | 61740(28) | Rear counterweight |
22050(10) | Central counterweight |
Slewing radius | ft(m) | 15'5"(4.7) | |
Overall dimensions(L × W × H) | m | 45'3"×11'2"×11'(13.8×3.4×3.35) | |
Ground clearance of the undercarriage | ft(mm) | 17"(437) | |
Engine | Type | | Cummins QSL9-280 | |
Rated power | HP@RPM(Kw@RPM) | 280@2100(209@2100) |
Max. output torque | Lbs?ft@RPM(N?m@RPM) | 1050@1500(1424@1500) |
Exhaust standard | | According to U.S.EPA Tier 3 |
Distance between track center×crawler contact length×crawler width | ft(m) | 8'2"×17'10"×2'7"(2.5×5.44×0.8) | Crawler carrier retracted |
13'9"×17'10"×2'7"(4.2×5.44×0.8) | Crawler carrier extende |
